Product Description
General Information
|
Manufacturer |
Foxboro |
|---|---|
|
Model Number |
FCP270 |
|
Description |
Field Control Processor |
Environmental Specifications
|
Condition |
Operating |
Storage |
|---|---|---|
|
Temperature |
0 to +60°C (+32 to +140°F) |
-40 to +70°C (-40 to +158°F) |
|
Relative Humidity |
5% to 95% (noncondensing) |
5% to 95% (noncondensing) |
|
Altitude |
-300 to +3,000 m (-1,000 to +10,000 ft) |
-300 to +12,000 m (-1,000 to +40,000 ft) |
|
Contamination |
Class G3 (Harsh) per ISA S71.04; Pollution Degree 2 per IEC 664-1 |
|
|
Vibration |
0.5 g (5 to 500 Hz) |
– |
Physical Specifications
|
Parameter |
Specification |
|---|---|
|
Configuration |
Single processor moduleFault-tolerant version uses two interconnected modules |
|
Mounting |
Device-specific 2- or 4-position baseplates (horizontal or vertical) |
|
Dimensions |
Height: 103 mm (4.04 in), 114 mm (4.5 in) with lugsWidth: 51.5 mm (2.03 in)Depth: 147 mm (5.80 in) |
|
Mass |
0.6 kg (1.3 lb) (non-fault-tolerant module) |
Fiber Optic Cabling (Ethernet Switch to FCP270)
|
Component |
Specification |
|---|---|
|
Ethernet Switch Connector |
One MT-RJ connector |
|
FCP270/Splitter Connector |
Two ceramic LC connectors with clip |
|
Cable Type |
Multimode fiber (MMF), 62.5/125 µm, plenum |
|
Standard Cable Lengths |
3 m (9.9 ft), 15 m (49.5 ft), 50 m (165 ft) |
|
User-Supplied Lengths |
Greater than 50 m |
|
Maximum Distance |
2 km (6,560 ft) from Ethernet switch to FCP270 |
