Product Description
General Information
|
Field |
Details |
|---|---|
|
Manufacturer |
Foxboro |
|
Model/Part Number |
FBM232 P0926GW |
|
Description |
FBM232 Field Device System Integrator Module, 10/100 Mbps Ethernet, Single |
Environmental Specifications
|
Condition |
Temperature Range |
Relative Humidity |
|---|---|---|
|
Operating |
Rev A–J: -20 to +70°C (-4 to +158°F) Rev K and later: 0 to +70°C (32 to +158°F) |
5 to 95% (noncondensing) |
|
Storage |
-40 to +70°C (-40 to +158°F) |
5 to 95% (noncondensing) |
|
Contamination |
Suitable for Class G3 (Harsh) environments per ISA S71.04 and EIA 364-65 Class III |
Physical Specifications
|
Property |
Specification |
|---|---|
|
Mounting |
Modular Baseplate (horizontal/vertical DIN rail or 19” rack) |
|
Module Dimensions |
Height: 102 mm (4 in) / 114 mm (4.5 in incl. mounting lugs) Width: 45 mm (1.75 in) Depth: 104 mm (4.11 in) |
|
Weight |
284 g (10 oz) approximate |
|
Part Number |
P0926GW |
Cables and Connections
|
Type |
Specification |
|---|---|
|
Module to Device Length |
1 m (3.3 ft) to 100 m (330 ft) |
|
Connectors |
RJ-45 |
|
Optional Adapter Cable |
Null Hub Adapter Cable – P0971PK |
