Foxboro FBM217 P0916PW Discrete Input Module
Foxboro FBM217 P0916PW Discrete Input Module
Manufacturer: Foxboro
Product No.: FBM217 P0916PW
Condition:1000 in stock
Product Type: Discrete Input Module
Product Origin: USA
Payment: T/T, Western Union
Weight: 284g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
_
General Information
|
Field |
Details |
|---|---|
|
Manufacturer |
Foxboro |
|
Model Number |
FBM217 P0916PW |
|
Description |
Discrete Input Module |
_
_
Environmental Specifications
_
Operating Conditions
|
Parameter |
Value |
|---|---|
|
Temperature |
-20 to +70°C (-4 to +158°F) |
|
Relative Humidity |
5 to 95% (non-condensing) |
|
Altitude |
-300 to +3,000 m (-1,000 to +10,000 ft) |
_
Storage Conditions
|
Parameter |
Value |
|---|---|
|
Temperature |
-40 to +70°C (-40 to +158°F) |
|
Relative Humidity |
5 to 95% (non-condensing) |
|
Altitude |
-300 to +12,000 m (-1,000 to +40,000 ft) |
_
Other Environmental Parameters
|
Parameter |
Value |
|---|---|
|
Contamination |
Class G3 (Harsh) per ISA S71.04, tested to EIA 364-65, Class III |
|
Vibration |
0.75 m/s² (5 to 500 Hz) |
_
_
Physical Specifications
_
Module
|
Parameter |
Value |
|---|---|
|
Mounting |
Modular baseplate; DIN rail or 19-inch rack |
|
Mass |
284 g (10 oz) approx. |
|
Dimensions (H _ W _ D) |
114 _ 45 _ 104 mm (4.5 _ 1.75 _ 4.11 in) including mounting lugs |
_
Termination Assembly (Compression Type)
|
Parameter |
Value |
|---|---|
|
Mounting |
DIN rail (32 mm or 35 mm styles) |
|
Mass |
420_454 g (0.93_1.0 lb approx.) |
|
Length |
216 mm (8.51 in) or 233 mm (9.15 in) |
|
Construction Material |
Polyamide (PA) |
_
_
Termination Cables
|
Parameter |
Details |
|---|---|
|
Cable Length |
Up to 30 m (98 ft) |
|
Materials |
Polyurethane or LSZH |
|
Type 4 Connection |
Baseplate: 37-pin D-sub plug; TA: 37-pin receptacle |
|
Type 6 Connection |
Main TA: 25-pin receptacle; Expansion TA: 37-pin receptacle |
_
_
Field Termination Connections
|
Parameter |
Value |
|---|---|
|
Accepted Wire Sizes |
0.2 to 4 mm² solid, 0.2 to 2.5 mm² stranded, 24 to 12 AWG |
|
Stranded with Ferrules |
0.2 to 2.5 mm² with/without plastic collar |
_
_
Part Numbers
|
Component |
Part Number |
|---|---|
|
FBM217 Module |
RH914TR (supersedes P0914TR) |
|
Redundant Adapter |
RH926ZY (supersedes P0926ZY) |
|
Termination Assemblies |
Refer to functional specs, page 9 |
_
_
