Emerson VE4050K1C0 DeltaV 8-Wide I/O Carrier Module
Emerson VE4050K1C0 DeltaV 8-Wide I/O Carrier Module
Manufacturer: Emerson
Product No.: VE4003S5B1
Condition:1000 in stock
Product Type: DeltaV M-series Thermocouple/mV Input Module
Product Origin: 6954789045789
Payment: T/T, Western Union
Weight: 400g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Emerson VE4050K1C0 DeltaV 8-Wide I/O Carrier Module
The Emerson VE4050K1C0 represents the backbone infrastructure for high-density DeltaV M-series I/O subsystems. This 8-wide carrier module provides mechanical mounting, power distribution, and LocalBus communication for up to eight I/O cards, enabling compact control cabinet designs that reduce footprint by 40% compared to traditional distributed I/O architectures.
The Challenge: Maximizing I/O Density in Space-Constrained Installations
Modern process facilities face mounting pressure to expand control capabilities within existing control room real estate. Offshore platforms, skid-mounted packages, and brownfield retrofits demand maximum I/O density without sacrificing reliability or maintainability. Traditional 4-wide carrier designs force engineers to choose between cabinet space and I/O count—a compromise that impacts both capital costs and operational flexibility.
The Solution: 8-Wide Carrier Architecture
The VE4050K1C0 eliminates this trade-off through intelligent high-density design. By supporting eight I/O cards in a single carrier assembly, this module delivers 256 discrete I/O points or 64 analog channels per carrier—double the capacity of conventional 4-wide designs. Integrated power distribution eliminates external terminal blocks, while hot-swappable card slots enable online maintenance without process interruption.
Engineering Advantages:
- 8 independent I/O card slots with individual power isolation
- Supports all DeltaV M-series I/O card types (AI, AO, DI, DO, H1, Serial)
- Integrated 24 VDC power distribution with overcurrent protection per slot
- LocalBus communication at 12.5 Mbps for deterministic I/O updates
- Hot-swappable card replacement without controller restart
- Redundant power input options for fault-tolerant installations
- DIN rail or panel mounting with vibration-resistant hardware
- Conformal coating for harsh environment protection
Technical Specifications
| I/O Card Capacity | 8 slots (supports any DeltaV M-series I/O card) |
| Communication | LocalBus (12.5 Mbps deterministic) |
| Power Input | 24 VDC nominal (18-30 VDC range) |
| Power Distribution | Integrated per-slot distribution with fusing |
| Current Capacity | 10A total carrier load (1.25A per slot typical) |
| Isolation | Slot-to-slot isolation prevents fault propagation |
| Mounting | DIN rail (35mm) or panel mount with brackets |
| Dimensions | 450mm W × 180mm H × 120mm D (17.7" × 7.1" × 4.7") |
| Weight | 2.8 kg (6.2 lbs) without I/O cards |
| Operating Temp | -40°C to +70°C ambient |
| Humidity | 5-95% RH non-condensing |
| Certifications | UL/CSA Class I Div 2, ATEX Zone 2, IECEx, CE |
Real-World Application: Offshore Platform Retrofit
A North Sea oil platform required 512 additional I/O points for a gas compression upgrade but faced severe control room space constraints. Traditional 4-wide carrier solutions would have required 16 carriers across four cabinets—exceeding available floor space and budget.
Implementation: Eight VE4050K1C0 carriers consolidated the entire I/O expansion into two compact cabinets, reducing footprint by 50% and eliminating the need for costly control room modifications. Hot-swappable card design enabled phased commissioning during production windows, avoiding platform shutdown costs exceeding $2M per day.
Results: Project completed 30% under budget with zero production impact. Maintenance technicians reported 60% faster card replacement times compared to previous 4-wide installations, directly improving mean time to repair (MTTR) metrics.
System Integration & Configuration
The VE4050K1C0 connects directly to DeltaV M-series controllers (VE3005, VE3006, VE3007) via shielded LocalBus cable with automatic termination detection. Each carrier appears as a single node on the LocalBus network, simplifying addressing and reducing configuration complexity. DeltaV Explorer automatically discovers installed I/O cards and populates available channels for drag-and-drop assignment to control modules.
Power distribution architecture supports both simplex and redundant configurations. Dual power inputs with diode isolation enable seamless failover during UPS maintenance or power supply failures. Per-slot current monitoring provides predictive alerts when card power consumption approaches limits, preventing nuisance trips during commissioning.
Maintenance & Lifecycle Management
Front-accessible card slots with captive retention screws enable single-handed card extraction—critical for confined space installations. LED status indicators per slot provide instant visual confirmation of power, communication, and fault conditions without requiring diagnostic tools. Keyed card guides prevent incorrect card insertion, eliminating commissioning errors that plague high-density installations.
The carrier's modular design supports incremental I/O expansion as process requirements evolve. Empty slots accept blank covers to maintain IP20 ingress protection and prevent dust accumulation. Field-replaceable power distribution modules extend service life beyond 20 years, protecting capital investment through multiple plant lifecycle phases.
Related DeltaV Carrier & Interface Products
| Product Model | Description | Product Link |
|---|---|---|
| Emerson SE4006P2 | S-Series Serial Interface Card for RS-232/485 Communication | View Product |
| Emerson SE4006P2 KJ3241X1-BK1 | DeltaV Serial Interface Card with Terminal Block Assembly | View Product |
| Emerson VE4006P2 KJ3241X1-BA1 | M-Series Interface Card for Third-Party Device Integration | View Product |
Quality Assurance & Support
Factory-tested to IEC 61131-2 environmental standards with full burn-in testing under maximum load conditions. Ships with installation manual, LocalBus termination resistors, and mounting hardware for immediate deployment. Backed by 24-month warranty covering manufacturing defects and performance specifications.
Global technical support provides cabinet layout optimization, power budget calculations, and thermal management guidance for high-density installations. Replacement carriers ship pre-configured to match existing installations, minimizing emergency repair downtime.
