Emerson VE4032S1T2B1 KJ3202X1-BA1 Digital Output (DO) Module _ High-Side Switching
Emerson VE4032S1T2B1 KJ3202X1-BA1 Digital Output (DO) Module _ High-Side Switching
Manufacturer: Emerson
Product No.: KJ3202X1-BA1
Condition:1000 in stock
Product Type: Digital Output (DO) Module _ High-Side Switching
Product Origin: USA
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
___
Product Overview
|
Field |
Details |
|---|---|
|
Manufacturer |
Emerson |
|
Model/Part Number |
VE4032S1T2B1 / KJ3202X1-BA1 |
|
Model Type |
Digital Output (DO) Module _ High-Side Switching |
|
Description |
8-Channel Digital Output Module for 24 VDC high-side switching. Ideal for driving digital loads like solenoids and relays in control systems. Supports robust operation in industrial environments. |
_
_
_
Power Specifications
|
Parameter |
Specification |
|---|---|
|
Local Bus Power |
12 VDC @ 150 mA |
|
Bussed Field Power |
30 VDC @ 3 A |
|
Field Circuit Power |
30 VDC @ 1 A per channel, 3 A total/card |
_
_
__ï¸
Environmental Specifications
|
Parameter |
Specification |
|---|---|
|
Ambient Temperature |
-40°C to +70°C |
|
Shock |
10 g, ½ sinewave for 11 ms |
|
Vibration |
1 mm peak-to-peak (2_13.2 Hz); 0.7 g (13.2_150 Hz) |
|
Airborne Contaminants |
ISA-S71.04 _1985, Class G3 |
|
Relative Humidity |
5% to 95%, non-condensing |
|
Terminal Block Key |
Position B6 |
|
Ingress Protection |
IP20 |
_
