Product Description
🔍
Product Overview
|
Field |
Details |
|---|---|
|
Manufacturer |
Emerson |
|
Model/Part Number |
VE4032S1T2B1 / KJ3201X1-EA1 |
|
Model Type |
Digital Output (DO) Terminal Block |
|
Description |
Redundant discrete terminal block used with 8-channel 24 VDC digital output modules for interfacing with field wiring. Provides high-side switching control and reliable power distribution. |
⚡
Power Specifications
|
Parameter |
Specification |
|---|---|
|
Input Power Rating |
30 VDC @ 1 A per channel, 3 A total per card |
🌡️
Environmental Specifications
|
Parameter |
Specification |
|---|---|
|
Ambient Temperature |
-40 °C to +70 °C |
|
Shock |
10 g, half-sine wave for 11 ms |
|
Vibration |
1 mm peak-to-peak (2–13.2 Hz), 0.7 g (13.2–150 Hz) |
|
Airborne Contaminants |
ISA-S71.04 –1985, Class G3 |
|
Relative Humidity |
5% to 95%, non-condensing |
|
Protection Rating |
IP20 |
