Product Description
🔍 Product Overview
|
Field |
Details |
|---|---|
|
Manufacturer |
Emerson |
|
Model/Part Number |
VE4005S2B3 (Includes: KJ3221X1-BA1 + KJ4001X1-CE1) |
|
Description |
VE4005S2B3 is an 8-channel analog output module with HART capability, integrated with a 16-pin Mass Terminal Block for streamlined field connectivity. Designed for DeltaV systems. |
⚡ Power Specifications
KJ3221X1-BA1 AO 4–20 mA HART (8-Channel)
|
Parameter |
Specification |
|---|---|
|
Local Bus Power |
12 VDC @ 150 mA |
|
Bussed Field Power |
24 VDC @ 300 mA |
|
Field Circuit Power |
24 VDC @ 23 mA per channel |
KJ4001X1-CE1 Mass Terminal Block (16-Pin)
|
Parameter |
Specification |
|---|---|
|
Input Power Rating |
30 VDC @ 1 A per channel |
🌡️ Environmental Specifications
|
Parameter |
Specification |
|---|---|
|
Ambient Temperature |
-40 °C to +70 °C |
|
Shock |
10 g, half-sine wave for 11 ms |
|
Vibration |
1 mm peak-to-peak (2–13.2 Hz); 0.7 g (13.2–150 Hz) |
|
Airborne Contaminants |
ISA-S71.04 –1985 Class G3 |
|
Relative Humidity |
5% to 95%, non-condensing |
|
Terminal Block Key |
A4 |
|
Protection Rating |
IP20 |
