Product Description
🔍 Product Overview
|
Field |
Details |
|---|---|
|
Manufacturer |
Emerson |
|
Model/Part Number |
VE4002S1T2B5 (includes KJ4001X1-CJ1) |
|
Description |
KJ4001X1-CJ1 – 32-Channel Terminal Block for I/O cards in the DeltaV™ Series 2 architecture. Supports standard 30 VDC signal interfacing. |
⚡ Power Specifications
|
Parameter |
Specification |
|---|---|
|
Input Power Rating |
30 VDC @ 1 A |
🌡️ Environmental Specifications
|
Parameter |
Specification |
|---|---|
|
Ambient Temperature |
-40 °C to +70 °C |
|
Shock |
10 g half-sine wave for 11 ms |
|
Vibration |
1 mm peak-to-peak from 2 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz |
|
Airborne Contaminants |
ISA-S71.04 –1985 Class G3 |
|
Relative Humidity |
5% to 95%, non-condensing |
