Product Description
Emerson VE4001S2T2B4 Discrete Input Module
Product Overview
- The Emerson VE4001S2T2B4, also referenced as KJ3203X1-BA1 with part number 12P3270X022, is a Discrete Input Module designed for the DeltaV Distributed Control System (DCS). Part of the M-series, this module processes 32 channels of 24 VDC discrete input signals (dry contact type) from field devices, such as switches and sensors, for use in safety-critical and process control applications. It is widely used in industries like oil and gas, chemical, and power generation, offering reliable integration with DeltaV controllers.
Technical Specifications
- The VE4001S2T2B4 (KJ3203X1-BA1, 12P3270X022) has the following specifications based on documentation from Emerson and industry sources:
| Specification | Details |
|---|---|
| Model/Part Number | VE4001S2T2B4 (KJ3203X1-BA1, 12P3270X022) |
| Manufacturer | Emerson |
| Description | Discrete Input Module |
| Series | DeltaV M-series |
| Input Channels | 32 channels, dry contact |
| Input Voltage | 24 VDC |
| Input Current | 2 mA per channel (typical) |
| Isolation | Channel-to-channel and channel-to-system isolation |
| Power Consumption | Approx. 3 W (from DeltaV system power) |
| Termination | 32-channel terminal block |
| Operating Temperature | -40°C to 70°C (-40°F to 158°F) |
| Dimensions | Approx. 130 mm x 41 mm x 107 mm |
| Weight | Approx. 0.3 kg |
| Mounting | DeltaV I/O carrier (vertical orientation) |
Additional Details
- The VE4001S2T2B4 includes the following additional information based on documentation from Emerson, Radwell, and other industry sources:
- Function: Processes 32 discrete input signals (24 VDC, dry contact) from field devices, converting them into digital data for DeltaV controllers; supports high-density applications with reliable signal processing and diagnostic capabilities for fault detection.
