Product Description
Product Overview
| Parameter | Details |
|---|---|
| Product Name | IS AI 4-20 mA HART CHARM |
| Model Number | SE4307T01 |
| Category | Intrinsically Safe (IS) CHARMs |
| Function | Analog Input 4-20 mA with or without HART communication |
| System Compatibility | DeltaV v11.3.1 or later (with SD Plus, SX, SQ, MQ, MX, PK Controllers) |
| Terminal Block | IS Terminal Block (Light Blue, 4 terminals) |
Hardware & Electrical Specifications
| Specification | Value |
|---|---|
| Sensor Types | 4-20 mA with or without HART; supports 2-wire and 4-wire device types |
| Nominal Signal Range (Span) | 4-20 mA (0-20 mA optional) |
| Full Signal Range | 0 to 22 mA |
| Input Impedance | 360 Ω |
| Field Power (2-Wire) | 16.0 V (min) at 20 mA |
| Accuracy Over Temperature Range | 0.1% of span (0 to 60°C); 0.25% of span (-40 to 70°C) |
| Repeatability | 0.05% of span |
| Resolution | 16-bit A/D converter |
| Calibration | None required |
| Isolation | Galvanically isolated per EN 60079-11; voltage peak value 375 V DC |
| CHARM Power Requirement | 60 mA max @ 24 V DC ± 10% |
| CHARM Heat Dissipation | 0.86 W |
| HART Support | HART v7 pass-through for AMS; HART v7 variable and device status available to control |
| HART Data Update Rates | Typically less than one second, dependent on HART communication loading and device capability |
Environmental Specifications
| Parameter | Value |
|---|---|
| Operating Temperature | -40 to 70°C (or -40 to 60°C for fanless enclosures) |
| Storage Temperature | -40 to 85°C |
| Relative Humidity | 5 to 95%, non-condensing |
| Protection Rating | IP20 |
| Airborne Contaminants | ISA-S71.04-1985 Class G3, Conformal coating |
| Shock | 10 g ½-sine wave for 11 ms |
| Vibration | 1 mm peak-to-peak from 2 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz |
Functional Features
| Feature |
|---|
| Supports 4-20 mA input with or without HART communication |
| Configurable for 0-20 mA input |
| Supports 2-wire and 4-wire device types |
| LED Indicators: |
| - Power/Integrity (Bi-color): Green Solid (Normal), Green Blink (Awaiting configuration), Red Blink (Wiring fault), Red Solid (Internal fault) |
| Galvanic isolation per channel for intrinsically safe applications |
| Acts as a circuit protection device and field wiring disconnect |
| Surge protection to meet EMC industry standards |
| Can be partially ejected to a locked position for field maintenance |
Certifications
| Standard | Details |
|---|---|
| CE | EMC - EN 61326-1 |
| FM (USA) | Class I, Div 2, Groups A, B, C, D, T4; Class I, Zone 2, AEx ec [ia Ga] IIC T4 Gc; Field Circuits: Class I, II, III, Div 1, Group A-G, T4 |
| CSA (Canada) | Class I, Div 2, Groups A, B, C, D, T4; Class I, Zone 2, Ex ec [ia Ga] IIC T4 Gc; Field Circuits: Class I, II, III, Div 1, Group A-G, T4 |
| ATEX | II 3(1) G Ex ec [ia Ga] IIC T4 Gc; II 3 G (1D) Ex ec [ia IIIC Da] IIC Gc |
| IEC-Ex | II 3(1) G Ex ec [ia Ga] IIC T4 Gc; II 3 G (1D) Ex ec [ia IIIC Da] IIC Gc |
| Marine | DNV Marine Certificate; IACS E10 |
| Achilles | CIOC: Level 1 (v13.3.1); CIOC2: Level 2 (v14.3) |
Physical & Installation
| Parameter | Details |
|---|---|
| Installation Type | Mounted on IS CHARM Baseplate (DIN rail) |
| Wiring | 4 screw cage terminals, 0.32–2.5 mm² (22–14 AWG), 7–9 mm strip length (IS Terminal Block) |
| Maximum Current | 45 mA at 28 V DC max |
| Terminal Block Color | Light Blue (Intrinsically Safe) |
| Keying | Keying posts automatically set on first CHARM insertion; can be manually reset to change CHARM type |
| Removal/Insertion | Can be partially ejected to a locked position for field maintenance; full removal requires non-hazardous area or de-energized system |
| Maintenance | No user-serviceable parts; calibration not required |
Hazardous Area Installation
| Parameter | Details |
|---|---|
| Installation Instructions | Refer to ATEX/IECEx installation instructions (12P6523); Control Drawings (12P6123) |
| Hazardous Area Standards | Suitable for Class I, Div 2, Groups A, B, C, D, T4; Class I, Zone 2, AEx/Ex ec [ia Ga] IIC T4 Gc; ATEX II 3(1) G Ex ec [ia Ga] IIC T4 Gc |
Ordering Information
| Description | Model Number |
|---|---|
| IS AI 4-20 mA HART CHARM | SE4307T01 |
| IS CHARMs Baseplate Assembly with Standard IS CHARM Terminal Blocks | SE4608T01 |
| IS CHARM Protection Cover (Package of 12) | SE6104 |
