Product Description
Product Details
|
Manufacturer |
Emerson |
|---|---|
|
Model Number |
PR6423/00R-030 |
|
Description |
8mm Eddy Current Sensor (Non-armored cable, Metric thread, 30mm case length) |
Performance Specifications
|
Parameter |
Specification |
|---|---|
|
Linear Measurement Range |
2 mm (80 mils) |
|
Initial Air Gap |
0.5 mm (20 mils) |
|
Incremental Scale Factor (ISF) |
8 V/mm (203.2 mV/mil) ± 5% @ 0 to 45°C |
|
Deviation from Straight Line (DSL) |
±0.025 mm (±1 mil) @ 0 to 45°C |
|
Minimum Shaft Diameter |
25 mm (0.79 in) |
|
Target Material |
42CrMo4 (AISI/SAE 4140), others available on request |
Environmental Specifications
|
Parameter |
Specification |
|---|---|
|
Protection Class |
IP66 (IEC 60529) |
|
Sensor Operating Temp. |
-35 to +180°C (-31 to 356°F) |
|
Cable & Connector Temp. |
-35 to +150°C (-31 to 302°F) |
|
Sensor Tip Material |
PEEK (Polyether Ether Ketone) |
|
Case Material |
Stainless Steel |
|
Cable Material |
PTFE (Polytetrafluoroethylene) |
|
Connector Material |
Brass, Nickel-plated |
|
Weight (with 1m cable) |
Approx. 100 g (3.53 oz) |
Compliance & Certifications
|
Standard/Directive |
Compliant |
|---|---|
|
CE |
2014/30/EU, 2014/34/EU, 2011/65/EU |
|
ATEX |
EN 60079-0, EN 60079-11 |
|
IEC-Ex |
IEC 60079-0, IEC 60079-11, IEC 60079-26 |
Ordering Configuration Options
|
Tip Diameter |
8 mm |
|---|---|
|
Case Threads |
M10x1 (PR6423/00 or PR6423/01), or 3/8”-24 UNF (PR6423/10 or PR6423/11) |
|
Armored Cable |
No (PR6423/00, PR6423/10), Yes (PR6423/01, PR6423/11), Reverse Mount optional (PR6423/03, PR6423/13) |
|
Case Length Options |
25, 35, 45, 55, 65, 75, 85, 95, 105, 115, 155, 195 mm |
|
Adapter Plug |
With or Without |
|
Cable Length Options |
4.0m, 5.0m, 8.0m, 9.0m, 10.0m |
|
Cable End |
Lemo*, Open End |
Special Radiation-Hardened Version (PR6423/xxx-xxx-RAD)
|
Differences from Standard |
Specification |
|---|---|
|
Sensor Tip Material |
Epoxy Resin |
|
Case Material |
Stainless Steel with EPDM O-ring |
|
Cable Material |
Polyolefine |
|
Operating Temperature |
-35 to +80°C (-31 to 176°F) |
|
Radiation Resistance |
Up to 80 Mrad (Sensor & 1m Cable) |
|
Calculated Lifetime |
18.26 years (neutron), 183 years (beta/gamma) |
|
Certifications |
No hazardous area certification |
