Emerson ___vation OCR1100 Ovation Controller Model
Emerson ___vation OCR1100 Ovation Controller Model
Manufacturer: Emerson
Product No.: OCR1100
Condition:1000 in stock
Product Type: Ovation Controller Model
Product Origin: USA
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Product Details
Manufacturer:_Emerson
Model/Part Number:_OCR1100
Description: Ovation Controller Model
Ovation Controller OCR1100 Specifications
General Specifications
|
Item |
Capability |
|---|---|
|
Bus structure |
CompactPCI standard |
|
Originated points |
Up to 32,000 points |
|
Process control tasks |
Up to 5, each with a different loop execution rate |
|
Control task loop execution time |
- Ovation 3.6 and below: Two predefined @ 1 sec and @ 100 ms, three user-defined (10 ms to 300 sec in 10 ms increments)__- Ovation 3.7: All 5 tasks are user-defined (10 ms to 300 sec in 10 ms increments) |
|
Processor base frequency |
1.1 GHz |
|
Memory |
1 GB Flash & 256 MB RAM |
|
NIC ports |
- 4 x 10/100 Mb Ethernet__- Two options: (i) 4 x RJ45 or (ii) 1 x RJ45 + 3 SFP Fiber |
|
Power |
24 VDC 40W |
|
Humidity |
0 - 95% RH |
|
CE Mark |
Certified to be CE Mark compliant when installed in a CE Mark cabinet |
|
BootROM |
OCR1100 only |
|
Achilles Level 1 Certification |
Yes |
_
I/O Capabilities
|
Item |
Capability |
|---|---|
|
Local Ovation I/O |
Up to 16 independent branches (8 modules per branch, total of 128 I/O modules) |
|
Local Q-Line I/O |
1 node of 48 Q-Line I/O cards |
|
Extended Q-Line I/O |
1 additional node of 48 Q-Line I/O cards |
|
Remote Node Interface |
Up to 16 remote node interface modules (each supporting up to 64 I/O modules) |
|
Remote Ovation I/O |
Up to 8 nodes (each supporting up to 64 I/O modules) |
|
Remote Q-Line I/O |
Up to 8 nodes of 48 Q-Line I/O cards |
|
Smart Device Capability |
- FOUNDATION_ Fieldbus__- PROFIBUS__- DeviceNet__- Virtual I/O via Ethernet (TCP/IP and standard protocols) |
_
External Network Communication Support
__Allen-Bradley PLCs (DF-1)
__GE Mark V/VI GSM
__Modbus/TCP
__MHI turbine control
__GE Genius I/O
__Toshiba turbine control
_
Physical Dimensions & Environmental Limits
|
Specification |
Values |
|---|---|
|
Size (H x W x D) |
79 x 24 x 24 in (2006.6 x 609.6 x 609.6 mm) |
|
Weight (Fully Configured) |
426.25 lbs. (191.81 kg)__396.25 lbs. (178.31 kg) |
|
Operating Temperature |
- 4 x RJ45 ports: 0-50°C (32-122°F)__- 1 x RJ45, 3 x SFP ports: 0-40°C (32-104°F)__- General: 0-60°C (32-140°F) |
|
Storage Temperature |
-40 to 70°C (-40 to 158°F) |
|
Operating Humidity |
0 - 95% RH (Non-condensing) |
|
Storage Humidity |
0 - 95% RH (Non-condensing) |
_
Capacity
|
Configuration |
Capability |
|---|---|
|
Redundant Controllers |
Yes |
|
I/O Modules |
32 I/O modules |
|
Power Supplies |
2 power supplies |
|
Additional Space |
Space for spare equipment, 32 I/O modules, 2 power supplies |
_
