🌡️ Emerson Ovation 5X00119G01 RTD Input Module

Precision temperature acquisition for mission-critical process control. The 5X00119G01 RTD input module delivers 8 channels of high-accuracy resistance temperature detector (RTD) signal conditioning, purpose-built for Emerson Ovation distributed control systems in power generation, petrochemical, and pharmaceutical environments.

⚙️ Technical Specifications

• Input Channels: 8 independent RTD inputs
• RTD Types Supported: Pt100, Pt1000, Ni120, Cu10 (2-wire, 3-wire, 4-wire configurations)
• Measurement Range: -200°C to +850°C (-328°F to +1562°F)
• Accuracy: ±0.1°C typical at 25°C ambient
• Resolution: 16-bit A/D conversion for superior signal fidelity
• Isolation: Channel-to-channel and channel-to-backplane isolation for noise immunity
• Update Rate: Configurable scan rates up to 10 Hz per channel
• Operating Temperature: 0°C to +60°C (32°F to 140°F)

🏭 Industrial Applications

Power Generation: Monitor turbine bearing temperatures, feedwater heater performance, and condenser vacuum systems with fail-safe accuracy.

Chemical Processing: Track reactor vessel temperatures, distillation column profiles, and heat exchanger efficiency across multi-stage operations.

Pharmaceutical Manufacturing: Ensure GMP compliance with validated temperature monitoring in sterilization cycles, fermentation tanks, and cleanroom HVAC systems.

✅ Key Advantages

✓ Hot-Swappable Design: Replace modules without system shutdown—minimize downtime in 24/7 operations
✓ Self-Diagnostics: Built-in sensor break detection, out-of-range alarms, and module health monitoring
✓ Seamless Integration: Native compatibility with Ovation Controller and Ovation Developer Studio programming environment
✓ Harsh Environment Ready: Conformal coating protects against humidity, dust, and chemical exposure

🔧 System Integration

The 5X00119G01 mounts directly into Ovation I/O bases and communicates via the high-speed Ovation network. Configuration is performed through Ovation Developer Studio, where engineers define RTD types, linearization curves, engineering units, and alarm setpoints. The module automatically compensates for lead resistance in 3-wire RTD installations, ensuring measurement integrity across long cable runs.

📦 What's Included

Each 5X00119G01 module ships with terminal block assembly, installation guide, and certificate of conformity. Compatible with standard Ovation mounting rails and requires 24 VDC system power.

Backed by Emerson's global support network and designed for 15+ year service life in continuous industrial duty.
