Emerson KL3002X1-BA1 DO 24 VDC High Side CHARM
Emerson KL3002X1-BA1 DO 24 VDC High Side CHARM
Manufacturer: Emerson
Product No.: KL3002X1-BA1
Condition:1000 in stock
Product Type: DO 24 VDC High Side CHARM
Product Origin: USA
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
General Information
|
Field |
Description |
|---|---|
|
Manufacturer |
Emerson |
|
Model/Part Number |
KL3002X1-BA1 |
|
Description |
DO 24 VDC High Side CHARM |
_
_
Power Specifications
|
Parameter |
Value |
|---|---|
|
CHARM Bus Power |
+6.3 VDC at 32 mA |
|
Field Circuit Power |
+24 VDC at 5 mA |
_
_
Environmental Specifications
|
Parameter |
Value |
|---|---|
|
Ambient Temperature |
-40°C to +70°C |
|
Shock |
10g ½ sine wave for 11 ms |
|
Vibration |
1 mm Peak to Peak (2_13.2 Hz);0.7g (13.2_150 Hz) |
|
Airborne Contaminants |
ISA-S71.04_1985 Class G3 |
|
Relative Humidity |
5% to 95% Non-Condensing |
|
Terminal Block Key |
3C |
_
_
Important Notes
_
-
Hazardous Area Installation:
_
-
Follow_Document 12P5403___DeltaV_ Electronic Marshalling Digital Automation System (CHARM I/O Subsystem) Zone 2 Installation Instructions
-
Additional guidelines in_DeltaV_ S-series and CHARMs Hardware Installation Manual
-
Installation/Removal:
_
-
Only permissible when_de-energized_or in a_non-hazardous area
-
Requires_I/O loop assessment_for energy-limited nodes
-
Terminal Block Keying:
_
-
Keys_set on first CHARM installation
-
To change CHARM type,_reset key_by removing terminal block and unlocking key position
-
Maintenance:
_
-
No user-serviceable parts
-
Do not disassemble
-
No calibration required
_
