Product Description
General Information
|
Field |
Details |
|---|---|
|
Manufacturer |
Emerson |
|
Model/Part Number |
PR6424/010-110 |
|
Description |
Eddy Current Signal Converter |
Dynamic Performance
|
Parameter |
Value |
|---|---|
|
Sensitivity/Linearity |
4 V/mm (101.6 mV/mil) ≤ ±1.5% |
|
Air Gap (Center) |
Approx. 2.7 mm (0.11”) Nominal |
|
Long Term Drift |
< 0.3% |
|
Static Range |
±2.0 mm (0.079”) |
|
Dynamic Range |
0 to 1,000μm (0 to 0.039”) |
Target Specifications
|
Parameter |
Value |
|---|---|
|
Target/Surface Material |
Ferromagnetic Steel (42 Cr Mo4 Standard) |
|
Maximum Surface Speed |
2,500 m/s (98,425 ips) |
|
Shaft Diameter |
≥80mm |
Environmental Limits
|
Parameter |
Value |
|---|---|
|
Operating Temperature Range |
-35 to 150°C (-31 to 302°F) |
|
Temperature Error |
<4%/100°K (API 670 Compliant) |
|
Pressure Resistance (Sensor Head) |
10,000 hPa (145 psi) |
|
Shock and Vibration |
5g @ 60Hz @ 25°C (77°F) |
Physical Specifications
|
Parameter |
Value |
|---|---|
|
Material |
Sleeve – Stainless Steel, Cable – PTFE |
|
Weight (Sensor & 1M Cable, no Armor) |
~200 grams (7.05 oz) |
Ordering Information
|
Parameter |
Options |
|---|---|
|
Sleeve Thread |
M18x1.5 (0) / 3/4”-16 UNF (1) |
|
Armored Cable |
With (1) / Without (0) |
|
Total Sensor Length |
C = Cx +12.5mm (Cx options: 40mm to 290mm) |
|
Adaptor Plug |
With (0) / Without (1) |
|
Total Cable Length |
4m (0), 5m (1), 8m (3), 10m (4) |
|
Cable End |
LEMO (0) / OPEN (1) |
