Emerson EPRO ___R6423/01M-030+CON011 Eddy Current Signal Converter with Sensor
Emerson EPRO ___R6423/01M-030+CON011 Eddy Current Signal Converter with Sensor
Manufacturer: Emerson
Product No.: PR6423/01M-030+CON011
Condition:1000 in stock
Product Type: Eddy Current Signal Converter with Sensor
Product Origin: USA
Payment: T/T, Western Union
Weight: 100g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
General Information
|
Manufacturer |
Emerson |
|---|---|
|
Model/Part Number |
PR6423/01M-030+CON011 |
|
Description |
Eddy Current Signal Converter with Sensor |
_
Performance
|
Parameter |
Value |
|---|---|
|
Linear Measurement Range |
2 mm (80 mils) |
|
Initial Air Gap |
0.5 mm (20 mils) |
|
Incremental Scale Factor (ISF) |
8 V/mm (203.2 mV/mil) ± 5% (ISO Standard) |
|
Deviation from Best Fit Straight Line (DSL) |
± 0.025 mm (± 1 mil) @ 0 to 45°C (+32 to +113°F) |
_
Measuring Target
|
Parameter |
Value |
|---|---|
|
Minimum Shaft Diameter |
25 mm (0.79_) |
|
Target Material |
Ferromagnetic Steel (42CrMo4 / AISI/SAE 4140 Standard) |
|
Other Materials |
Available on request |
_
Environmental & General Information
|
Parameter |
Value |
|---|---|
|
Protection Class |
IP66 (IEC 60529) |
|
Operating Temperature Range (Sensor + 1m Cable) |
-35 to +180°C (-31 to 356°F) |
|
Operating Temperature Range (Cable & Connector) |
-35 to +150°C (-31 to 302°F) |
|
Material (Sensor Tip) |
PEEK (Polyether Ether Ketone) |
|
Material (Case) |
Stainless Steel |
|
Material (Cable) |
PTFE (Polytetrafluoroethylene) |
|
Material (Connector) |
Brass, nickel-plated |
|
Weight (Sensor with 1m Cable) |
Approx. 100 grams (3.53 oz) |
_
Ordering Information
Tip Diameter, Case Threads, and Armored Cable Options
|
Tip Diameter |
Case Threads |
Armored Cable |
Model No. |
|---|---|---|---|
|
8mm |
M10x1 |
No |
PR6423/00 |
|
8mm |
M10x1 |
Yes |
PR6423/01 |
|
8mm |
M10x1 |
Yes (Reverse Mount Option) |
PR6423/03* |
|
8mm |
3/8_-24 UNF |
No |
PR6423/10 |
|
8mm |
3/8_-24 UNF |
Yes |
PR6423/11 |
|
8mm |
3/8_-24 UNF |
Yes (Reverse Mount Option) |
PR6423/13* |
Note:_Armored cable option available for Reverse Mount if Adapter Plug is chosen.
Additional Model Configurations
|
Model No. |
Case Thread |
Adapter Plug |
Cable Length |
Cable End |
|---|---|---|---|---|
|
PR6423/00 |
X |
X |
X |
X |
|
PR6423/01 |
X |
X |
X |
X |
|
PR6423/10 |
X |
X |
X |
X |
|
PR6423/11 |
X |
X |
X |
X |
Cable Length Options
|
Code |
Length |
|---|---|
|
0 |
4.0m |
|
1 |
5.0m |
|
3 |
8.0m |
|
F |
9.0m |
|
4 |
10.0m |
Cable End Options
|
Code |
Connector Type |
|---|---|
|
0 |
Lemo* |
|
1 |
Open |
_
CON011 - Eddy Current Signal Converter
Dynamic Performance
|
Parameter |
Value |
|---|---|
|
Frequency Range (-3 dB) |
0 to 20000 Hz |
|
Rise Time |
<15 µs |
|
Compatible Sensor Types |
PR6422, PR6423, PR6424, PR6425, PR6426 |
|
Extended Measuring Range |
Available with CON011/91x-xxx |
|
Special Note |
PR6425 requires an extended range converter |
_
Environmental Specifications
|
Parameter |
Value |
|---|---|
|
Operating Temperature Range |
-30 to 100°C (-22 to 212°F) |
|
Shock and Vibration |
5g @ 60 Hz @ 25°C (77°F) |
|
Protection Class |
IP65 |
_
Power & Electrical
|
Parameter |
Value |
|---|---|
|
Supply Voltage Range |
-23V to -32V (Output Range: -4V to -20V) |
|
Alternative Supply Voltage Range |
-21V to -32V (Output Range: -2V to -18V) |
_
Physical Specifications
|
Parameter |
Value |
|---|---|
|
Housing Material |
GD-ALSi9Cu3 |
|
Weight |
~600 grams (21.16 oz) |
|
Mounting |
4 Screws M5x20 (Included) |
|
Connections |
Transducer: Self-Locking Lemo-Plug |
|
Power/Output |
Spring Type (Max. 1.5mm²) |
_
Compliance and Certifications
|
Regulation |
Standard |
|---|---|
|
CE |
2014/30/EU (EN 61326-1) |
|
CE |
2014/34/EU |
|
CE |
2011/65/EU |
|
ATEX |
EN 60079-0 |
|
ATEX |
EN 60079-11 |
_
Ordering Information
|
Part Number |
Sensor Type |
Measuring Range |
Linearity Error |
|---|---|---|---|
|
CON011 |
PR6422, PR6423, PR6424, PR6426 |
1.0mm - 8.0mm (Standard Range) |
_ 1.0% - 1.5% |
|
CON011/912-015 |
PR6422 |
1.5mm (Extended Range) |
_ 2.0% |
|
CON011/913-030 |
PR6423 |
3.0mm (Extended Range) |
_ 1.5% |
|
CON011/913-040 |
PR6423 |
4.0mm (Extended Range) |
_ 2.0% |
|
CON011/914-060 |
PR6424 |
6.0mm (Extended Range) |
_ 1.0% |
|
CON011/914-080 |
PR6424 |
8.0mm (Extended Range) |
_ 1.5% |
|
CON011/914-100 |
PR6424 |
10.0mm (Extended Range) |
_ 2.0% |
|
CON011/915-040 |
PR6425 |
4.0mm (Standard Range) |
_ 1.5% |
|
CON011/915-060 |
PR6425 |
6.0mm (Extended Range) |
_ 2.0% |
|
CON011/915-080 |
PR6425 |
8.0mm (Extended Range) |
_ 3.0% |
|
CON011/915-100 |
PR6425 |
10.0mm (Extended Range) |
_ 4.0% |
|
CON011/916-120 |
PR6426 |
12.0mm (Extended Range) |
_ 1.5% |
|
CON011/916-160 |
PR6426 |
16.0mm (Extended Range) |
_ 2.0% |
|
CON011/916-200 |
PR6426 |
20.0mm (Extended Range) |
_ 2.5% |
|
CON011/916-240 |
PR6426 |
24.0mm (Extended Range) |
_ 3.5% |
_
