Product Description
General Information
|
Field |
Description |
|---|---|
|
Manufacturer |
Emerson |
|
Model/Part Number |
EP-7641 |
|
Description |
Power Module, 1 Channel, 24VDC Output, 10A Flow |
Functional Specifications
|
Parameter |
Value |
|---|---|
|
Supply Voltage |
20.4V – 28.8V |
|
Maximum Feed Current |
10 A (for output modules) |
|
Current Consumption (Output Path) |
10 mA |
|
Operating Temperature Range |
-20°C to +60°C (-4°F to +140°F) |
|
Storage Temperature Range |
-40°C to +85°C (-40°F to +185°F) |
|
Air Humidity (Operation/Transport) |
5% to 95%, non-condensing (IEC 61131-2) |
Physical Specifications
|
Parameter |
Value |
|---|---|
|
Width |
11.5 mm (0.45 in) |
|
Depth |
76 mm (2.99 in) |
|
Height |
120 mm (4.72 in) |
|
Weight |
76 g (6.21 oz) |
Summary
-
EP-7641 is a 24VDC output power module designed to supply up to 10A for output modules.
-
It is built for industrial environments with a compact size and wide temperature tolerance.
-
Humidity resistant according to IEC 61131-2 standards.
