Emerson 5X00569H01 Power Supply Module | Ovation DCS 24VDC

⚡ Emerson 5X00569H01 – Mission-Critical Power for Ovation DCS

When your distributed control system demands uninterrupted, clean 24 VDC power, the 5X00569H01 power supply module delivers. Engineered by Emerson for Ovation platforms, this module converts facility AC voltage into regulated DC output that keeps controllers, I/O racks, and communication interfaces online—even during voltage sags and transients.

💡 The Power Behind Process Uptime

Every Ovation controller, every I/O module, every network interface depends on stable DC rails. The 5X00569H01 integrates active power factor correction, over-current protection, and thermal management to maintain voltage regulation within ±2% across load swings. Built-in diagnostics signal fault conditions before they cascade into system shutdowns.

🎯 Deployment Scenarios

Refinery Control Rooms: Power redundant controller pairs in hydrocracker and FCC units where milliseconds of downtime translate to safety incidents and lost production.

Power Plant Auxiliaries: Energize boiler feedwater control loops, turbine protection systems, and emissions monitoring—applications where IEEE 1613 compliance is mandatory.

Pharmaceutical Batch Systems: Supply clean power to recipe controllers and data historians in FDA 21 CFR Part 11 environments requiring full audit trails.

Water Treatment SCADA: Drive remote I/O in lift stations and clarifiers where lightning-induced surges are routine threats.

🔧 Engineering Data

Input Voltage: 100–240 VAC, 50/60 Hz auto-ranging
Output: 24 VDC ±2%, up to 10 A continuous
Efficiency: >85% at full load (reduced heat, lower cooling costs)
Holdup Time: >20 ms at nominal load (rides through brief AC interruptions)
Isolation: 1500 VAC input-to-output, 500 VAC output-to-ground
Indicators: Green LED (DC OK), Red LED (fault latch)
Mounting: DIN rail (35 mm) or panel bracket
Operating Temp: 0°C to +60°C (derate above 50°C per manual)
Certifications: UL 508, CE, cULus, ATEX Zone 2 (when used with approved barriers)

🛡️ Built-In Protection Architecture

• Overvoltage Shutdown: Clamps output at 28 VDC to protect downstream logic
• Short-Circuit Proof: Auto-recovery after fault clears; no fuse replacement
• Reverse Polarity Guard: Prevents damage from miswired DC distribution
• Thermal Foldback: Reduces output current at elevated temperatures to prevent thermal runaway

✅ Why Engineers Specify 5X00569H01

Proven in Harsh Environments: Thousands deployed in refineries, chemical plants, and utilities—locations where ambient temperatures swing 40°C and electrical noise is constant.

Simplified Sparing: Universal AC input eliminates the need to stock region-specific models; one SKU serves global sites.

Lifecycle Support: Emerson maintains backward compatibility across Ovation generations; upgrade controllers without replacing power infrastructure.

📐 Integration Notes

Pair with Emerson 1C31xxx I/O modules and controller bases. For redundant configurations, deploy two 5X00569H01 units with diode-OR'd outputs per Ovation Redundancy Design Guide (D301234X012). Consult local codes for grounding and bonding—some jurisdictions require isolated DC systems.

Secure reliable power for your Ovation DCS with the 5X00569H01—engineered to keep critical processes running.
