Emerson 1X00569H01 Power Supply Module | Ovation 24VDC PSU
Emerson 1X00569H01 Power Supply Module | Ovation 24VDC PSU
Manufacturer: Emerson
Product No.: 1X00569H01
Condition:1000 in stock
Product Type: Ovation Power Supply Module
Product Origin: 8594217569401
Payment: T/T, Western Union
Weight: 1500g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
💡 Emerson 1X00569H01 – Ovation DCS Power Supply Module
Deliver uninterrupted 24 VDC power to your Emerson Ovation distributed control system with the 1X00569H01 redundant power supply module. Engineered for mission-critical process environments where voltage stability directly impacts production uptime and safety system integrity.
🔋 Power Architecture Overview
The 1X00569H01 converts facility AC mains (100–240 VAC) into regulated 24 VDC output, feeding controller racks, I/O modules, and field instrumentation. Built-in current limiting and thermal shutdown protect downstream electronics from fault conditions, while wide input voltage tolerance accommodates utility grid fluctuations common in industrial settings.
🎯 Deployment Scenarios
Refinery Control Rooms: Power ControlLogix processors and safety PLCs managing hydrocarbon processing units—environments where a single power glitch can trigger emergency shutdowns costing millions per hour.
Pharmaceutical Manufacturing: Sustain clean-room HVAC controls and batch reactor monitoring systems that demand FDA 21 CFR Part 11 compliant data integrity, impossible without stable power rails.
Water Treatment Facilities: Energize SCADA networks controlling pump stations and chemical dosing systems across distributed sites, where redundant supplies prevent service interruptions affecting entire municipalities.
⚙️ Technical Deep Dive
| Input Voltage | 100–240 VAC, 50/60 Hz (auto-sensing) |
| Output Voltage | 24 VDC ±2% (ripple <50 mV p-p) |
| Output Current | 10 A continuous, 12 A peak (3 sec) |
| Efficiency | >85% at full load (reduces heat dissipation) |
| MTBF | >200,000 hours (Telcordia SR-332) |
| Operating Temp | 0°C to +60°C (32°F to 140°F) |
| Certifications | UL 508, CE, RCM, EAC |
🛡️ Reliability Features
✔️ Redundancy Ready: Pair two 1X00569H01 modules in N+1 configuration; automatic load sharing ensures seamless failover if one unit degrades.
✔️ Diagnostic LEDs: Front-panel indicators show AC OK, DC OK, and overload status for rapid troubleshooting.
✔️ Conformal Coating: PCB protection against humidity, dust, and corrosive gases in harsh industrial atmospheres.
✔️ Hot-Swap Capable: Replace failed units without powering down the entire rack (when used with redundant partner).
📐 Integration Guidelines
Mount the 1X00569H01 in standard Ovation card cages using supplied retention clips. Connect AC input via terminal block (14–18 AWG wire); DC output distributes through backplane connectors to adjacent modules. For redundant operation, install second PSU in adjacent slot and enable load-sharing jumpers per Emerson installation manual SE-IM-1X00569.
🚀 Why Specify 1X00569H01?
Unlike generic DIN-rail supplies, the 1X00569H01 integrates natively with Ovation's diagnostic bus—system health monitoring software tracks voltage trends, predicts end-of-life, and logs power events for root-cause analysis. This intelligence transforms your power subsystem from passive infrastructure into an active reliability asset.
Ensure your Ovation DCS operates at peak performance. Order the 1X00569H01 power supply module today.
