| Input Channels |
16 digital inputs, arranged in two groups of 8 |
| Input Voltage |
24 V DC nominal (18-30 V DC) |
| Input Current |
7 mA per channel at 24 V DC |
| Isolation |
Channel-to-channel and channel-to-system isolation (500 V AC) |
| Signal Types |
Supports sinking or sourcing inputs, with configurable filtering |
| Power Supply |
24 V DC via ModuleBus or external power |
| Power Consumption |
3 W typical |
| Operating Temperature Range |
-25°C to +70°C |
| Mounting |
DIN rail mount, compatible with S800 I/O system |
| Dimensions |
119 mm x 45 mm x 102 mm (H x W x D) |
| Weight |
0.3 kg |
| Protection Rating |
IP20 |
| Standards Compliance |
IEC 61131-2, CE, UL, CSA |
