Product Description
Det-Tronics X3301A4M13T2 Multispectrum Infrared Flame Detector
- Manufacturer: Det-Tronics
- Model/Part Number: X3301A4M13T2
- Description: Multispectrum Infrared Flame Detector
Overview
- The Det-Tronics X3301A4M13T2 is a multispectrum infrared (MIR) flame detector designed for detecting hydrocarbon-based fires in hazardous industrial environments, such as oil and gas facilities, petrochemical plants, and power generation sites. It uses advanced signal processing to provide high sensitivity and false alarm rejection, suitable for both indoor and outdoor applications.
Technical Specifications
| Specification | Details |
|---|---|
| Model | X3301A4M13T2 |
| Type | Multispectrum Infrared Flame Detector |
| Material | Aluminum |
| Detection Technology | Multispectrum Infrared (three IR sensors) |
| Field of View | 90° cone of vision |
| Detection Range | Up to 265 ft (81 m) for n-heptane fire |
| Response Time | Typically <3 seconds |
| Input Voltage | 24 VDC nominal (18–30 VDC) |
| Power Consumption | 4.5 W (typical), 17 W (maximum with heater) |
| Output | Fire alarm, fault, and auxiliary relays; 0–20 mA with optional HART |
| Operating Temperature | -40°C to +75°C |
| Certifications | FM, CSA, ATEX, IECEx, SIL 2, EN 54-10 |
Additional Information
- Functionality: The X3301A4M13T2 uses three IR sensors with advanced signal processing to detect fires from light to heavy hydrocarbon fuels, including n-heptane, gasoline, and methane, with superior false alarm rejection. It features automatic optical integrity (oi®) testing every 60 seconds, heated optics for humid environments, and supports Modbus, HART, and Eagle Quantum Premier protocols.
