Product Description
Bently Nevada 70M303 Parameters
Product Overview
| Parameter | Details |
|---|---|
| Manufacturer | Bently Nevada |
| Series | Ranger Pro |
| Model/Part Number | 70M303 |
| Model Type | Wireless Triaxial Accelerometer |
| Product Name | Ranger Pro Wireless Triaxial Accelerometer |
| Application | Remote, continuous monitoring of vibration and temperature on rotating machinery for predictive maintenance |
| Compatibility | Ranger Pro Wireless Condition Monitoring system, ISA100.11a gateways, System 1 software |
| Function | Measures triaxial acceleration, velocity, and surface temperature; transmits data wirelessly |
Functional Specifications
| Parameter | Details |
|---|---|
| Sensor Type | Triaxial accelerometer with integrated temperature sensor |
| Wireless Standard | ISA100.11a compliant |
| Measurement Capabilities | Triaxial vibration (RMS, peak, peak-to-peak, velocity) and temperature |
| Power Supply | Battery-powered (replaceable lithium-thionyl chloride) |
| Battery Life | Up to 5 years depending on configuration and update rate |
| Environmental Rating | IP67, suitable for hazardous areas |
| Operating Temperature | -40°C to +80°C |
| Frequency Range | 0.5 Hz to 10 kHz |
| Dynamic Range | 80 dB |
| Gateway Support | Up to 50 devices per gateway |
| Certifications | FCC Part 15, KCC, ATEX/IECEx for hazardous locations |
