Product Description
General Information
|
Attribute |
Details |
|---|---|
|
Manufacturer |
Bently Nevada |
|
Series |
3300 |
|
Model/Part Number |
330930-065-01-00 |
|
Model Type |
3300 NSv Extension Cable |
Specifications
Electrical
|
Attribute |
Details |
|---|---|
|
Proximitor Sensor Input |
Accepts one noncontacting 3300 RAM or 3300 NSv Proximity Probe and Extension Cable |
|
Power Requirements |
-17.5 Vdc to -26 Vdc without barriers at 12 mA max consumption, -23 Vdc to -26 Vdc with barriers. Operation above -23.5 Vdc may reduce the linear range. |
|
Supply Sensitivity |
Less than 2 mV change in output voltage per volt change in input voltage. |
|
Output Resistance |
50 Ω |
System Weight (Typical)
|
Component |
Weight |
|---|---|
|
Probe |
14 to 150 g (0.5 to 5.3 oz) |
|
Extension Cable |
45 g/m (0.5 oz/ft) |
|
Armored Extension Cable |
64 g/m (0.7 oz/ft) |
|
Proximitor Sensor |
255 g (9 oz) |
Environmental Limits
|
Attribute |
Temperature Range |
|---|---|
|
Operating and Storage Temperature |
-52°C to +177°C (-62°F to +351°F) |
Ordering Information
3300 NSv Extension Cable (330930-AAA-BB-CC)
Ensure that the extension cable length and probe length add up to the Proximitor Sensor’s total length.
A: Cable Length Option
|
Option |
Length |
|---|---|
|
040 |
4.0 meters (13.1 feet) |
|
045 |
4.5 meters (14.8 feet) |
|
060 |
6.0 meters (19.7 feet) |
|
065 |
6.5 meters (21.3 feet) |
B: Connector and Cable Option
|
Option |
Description |
|---|---|
|
00 |
Without stainless steel armor |
|
01 |
With stainless steel armor, with FEP jacket |
|
02 |
With stainless steel armor, without FEP jacket |
|
03 |
Without stainless steel armor, with connector protector |
|
04 |
With stainless steel armor, with FEP jacket, with connector protector |
|
05 |
With stainless steel armor, without FEP jacket, with connector protector |
|
06 |
FluidLoc cable without stainless steel armor |
|
07 |
FluidLoc cable with stainless steel armor, with FEP jacket |
|
08 |
FluidLoc cable with stainless steel armor, without FEP jacket |
|
09 |
FluidLoc cable without stainless steel armor, with connector protector |
|
10 |
FluidLoc cable with stainless steel armor, with FEP jacket, with connector protector |
|
11 |
FluidLoc cable with stainless steel armor, without FEP jacket, with connector protector |
C: Agency Approval Option
|
Option |
Approval |
|---|---|
|
00 |
Not Required |
|
05 |
Multiple Approvals |
