| Specification |
Details |
| Model |
330881-BR-04-150-06-02 |
| Series |
3300 XL |
| Type |
PROXPAC XL Proximity Transducer Assembly (Eddy Current) |
| Probe Tip Diameter |
8 mm |
| Measurement Range |
2 mm (80 mils) linear range, 0.25–2.25 mm (10–90 mils) gap |
| Average Scale Factor |
7.87 V/mm (200 mV/mil) |
| Probe Sleeve Length |
150 mm (5.9 inches) |
| Probe Penetration |
Estimated 100–110 mm (based on similar models) |
| Total Length |
1.0 meter (3.3 feet) probe cable |
| Connector Type |
Direct field wiring to monitors (no external connector) |
| Fittings Option |
Metric conduit fittings (06) |
| Armor Option |
Standard cable (02) |
| Agency Approvals |
Multiple Approvals (CSA, ATEX, CE, assumed based on similar models) |
| Housing Material |
Polyphenylene sulfide (PPS) with glass and conductive fibers |
| Probe Tip Material |
Polyphenylene sulfide (PPS) |
| Probe Case Material |
AISI 303 or 304 stainless steel (SST) |
| Operating Temperature |
-52°C to +100°C (-62°F to +212°F) for housing; probe tip up to +177°C (+350°F) |
| Storage Temperature |
-52°C to +125°C (-62°F to +257°F) |
| Protection Rating |
IP66, Type 4X |
| Frequency Response |
0 Hz (DC) to 10 kHz |
| Weight |
Approximately 0.5–1.1 kg (1.1–2.4 lbs, estimated based on housing) |
| Mounting |
External mount, threaded ports for conduit |
| System Components |
Integrated 3300 XL 8 mm probe and Proximitor sensor |
| Interchangeability |
Compatible with 3300 XL monitors, not interchangeable with non-XL systems |
| Applications |
Radial vibration, axial position, Keyphasor signals |
