Product Description
General Information
|
Attribute |
Details |
|---|---|
|
Manufacturer |
Bently Nevada |
|
Series |
3300 |
|
Model/Part Number |
330102-XX-XX-10-02-05 |
|
Model Type |
Proximity Probes |
Description
The 3300 XL 8 mm Proximity Probes are designed to provide high-reliability measurements in various industrial environments. These probes include a Viton® O-ring for sealing differential pressure between the probe tip and the case. While they are not pressure-tested prior to shipment, custom testing options are available upon request.
Specifications
|
Attribute |
Details |
|---|---|
|
Probe Pressure Seal |
Sealed with Viton® O-ring |
|
Total System Weight (Typical) |
0.7 kg (1.5 lbm) |
|
Component Weights |
Probe: 323 g/m (11.4 oz) Extension Cable: 34 g/m (0.4 oz/ft) Armored Extension Cable: 103 g/m (1.5 oz/ft) Proximitor Sensor: 246 g (8.67 oz) |
Environmental Limits
|
Component |
Operating & Storage Temperature |
|---|---|
|
Standard Probe |
-52°C to +177°C (-62°F to +350°F) |
|
Extended Temperature Probe |
-52°C to +218°C (-62°F to +425°F) (probe tip) -51°C to +260°C (-60°F to +500°F) (probe cable & connector) |
Ordering Information
|
Part Number |
Description |
|---|---|
|
330102 |
3300 XL 8 mm Probe, 3/8-24 UNF thread, with armor |
