Product Description
Product Overview
The Bently Nevada 330102-00-28-05-02-05 is a Proximity Probe from the 3300 XL 8 mm series, designed for industrial automation and machinery condition monitoring. Manufactured by Bently Nevada (a Baker Hughes brand), this non-contact sensor uses eddy current technology to measure shaft vibration, displacement, and position in rotating machinery. It is engineered for high reliability in harsh industrial environments such as oil and gas, power generation, and manufacturing, making it ideal for applications involving turbines, compressors, pumps, and motors. The 330102 prefix indicates a specific configuration within the 3300 XL 8 mm family, tailored for precise monitoring.
Technical Specifications
The 330102-00-28-05-02-05 has the following specifications based on Bently Nevada documentation and supplier data:
| Item | Specification |
|---|---|
| Model/Part Number | 330102-00-28-05-02-05 |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Description | 3300 XL 8 mm Proximity Probe |
| Series | 3300 XL 8 mm |
| Probe Diameter | 8 mm |
| Total Length | 2.8 inches (71 mm, based on "00-28" code) |
| Unthreaded Length | 0.5 inches (13 mm, based on "05" code) |
| Measurement Range | 80 mil (2 mm) |
| Output Voltage | 7.87 V/mm (200 mV/mil) |
| Thread | 3/8-24 UNF-2A (based on "330102" code) |
| Operating Temperature | -51°C to 177°C (-60°F to 350°F) |
| Weight | 0.07 kg (0.15 lbs, approximate) |
Additional Details
The 330102-00-28-05-02-05 includes the following additional information based on supplier documentation:
| Category | Details |
|---|---|
| Function | Measures shaft vibration, displacement, and position |
| Compatibility | 3300 XL Proximitor and extension cables (e.g., 330130 series) |
| Configuration | Unarmored, no connector, standard mount (based on "02-05" codes) |
| Features | High linearity, RF immunity, rugged PPS tip material |
| Certifications | API 670 compliant, CE |
