Product Description
General Information
|
Attribute |
Details |
|---|---|
|
Manufacturer |
Bently Nevada |
|
Series |
3300 |
|
Model/Part Number |
330101-00-08-10-02-05 |
|
Model Type |
3300 XL 8 mm Probe |
Mechanical Specifications
|
Component |
Details |
|---|---|
|
Probe Tip Material |
Polyphenylene sulfide (PPS) |
|
Probe Case Material |
AISI 303 or 304 stainless steel (SST) |
|
Probe Cable Specifications |
|
|
- Standard Cable |
75Ω triaxial, fluoroethylene propylene (FEP) insulated |
|
- Extended Temperature Range Cable |
75Ω triaxial, perfluoroalkoxy (PFA) insulated |
|
- Armor (optional) |
Flexible AISI 302 or 304 SST with FEP outer jacket |
|
Tensile Strength |
330 N (75 lbf) from probe case to probe lead |
|
270 N (60 lbf) at probe lead to extension cable connectors |
|
|
Connector Material |
Gold-plated brass or gold-plated beryllium copper |
|
System Length Options |
5 or 9 meters (including extension cable), or 1 meter (probe only) |
|
Total System Weight |
0.7 kg (1.5 lb m) |
|
Probe Weight |
323 g/m (11.4 oz) |
Ordering Information
3300 XL 8 mm Proximity Probes
|
Part Number |
Description |
|---|---|
|
330101 |
3300 XL 8 mm Probe, 3/8-24 UNF thread, without armor |
|
330102 |
3300 XL 8 mm Probe, 3/8-24 UNF thread, with armor |
Configuration Options
|
Option |
Description |
|---|---|
|
A: Unthreaded Length Option |
Maximum unthreaded length: 8.8 in, Minimum: 0.0 in |
|
B: Overall Case Length Option |
Maximum case length: 9.6 in, Minimum: 0.8 in |
|
C: Total Length Option |
05: 0.5 meters (1.6 feet), 10: 1.0 meters (3.3 feet), 15: 1.5 meters (4.9 feet), 20: 2.0 meters (6.6 feet), 30: 3.0 meters (9.8 feet), 50: 5.0 meters (16.4 feet), 90: 9.0 meters (29.5 feet) |
