| Measurement Capabilities |
Shaft rotative speed, rotative acceleration, zero speed indication |
| Output Types |
Proportional voltage or current output on rear terminal strip |
| Alert Status |
Supplies Alert status via relay contacts for external annunciator panel |
| Power Consumption |
Nominal 2 watts |
| Input Signals |
Accepts Keyphasor or proximity probe signals |
| Frequency Range |
0 to 20,000 Hz (0 to 1,200,000 rpm) |
| Accuracy |
±0.25% of full scale at 25°C |
| Recorder Outputs |
User-programmable +4 to +20 mA, 0 to +10 Vdc, or +1 to +5 Vdc |
| Operating Temperature |
0°C to +65°C (+32°F to +150°F) |
| Storage Temperature |
-40°C to +85°C (-40°F to +185°F) |
| Relative Humidity |
Up to 95%, non-condensing |
| Full-scale Range Option (A) |
0-10,000 rpm |
| Transducer Input Option (B) |
Standard Keyphasor input |
| Alarm Relay Option (C) |
Hermetically-sealed |
| Agency Approval Option (D) |
ATEX self certification |
| Safety Barrier Option (E) |
Internal |
| Trip Multiply Option (F) |
2X |
