Product Description
General Information
|
Field |
Description |
|---|---|
|
Manufacturer |
Bently Nevada (a Baker Hughes business) |
|
Series |
3300 5 mm Proximity Transducer System |
|
Model/Part Number |
330173-00-04-20-12-05 |
|
Description |
5 mm Proximity Probe with M8 x 1 thread, no armor |
|
Application |
Measures shaft position/vibration in machinery |
Ordering Configuration Breakdown
|
Segment |
Value |
Description |
|---|---|---|
|
A |
00 |
Unthreaded length = 0 mm |
|
B |
04 |
Overall case length = 40 mm |
|
C |
20 |
Total system length = 2.0 meters |
|
D |
12 |
ClickLoc FluidLoc cable connector, no protector |
|
E |
05 |
Agency approvals (CSA, ATEX, IECEx) |
Mechanical Specifications
|
Parameter |
Value |
|---|---|
|
Thread Type |
M8 x 1 |
|
Unthreaded Length |
0 mm |
|
Case Length |
40 mm |
|
Tip Diameter |
5.2 mm |
|
Probe Case Material |
AISI 303 or 304 stainless steel |
|
Probe Tip Material |
Polyphenylene sulfide (PPS) |
|
Cable Diameter |
2.8 mm (standard), 7.6 mm (armored) |
|
Connector Type |
Miniature coaxial ClickLoc |
|
Cable Type |
75 Ω FEP-insulated triaxial |
|
Armor (if applicable) |
None (unarmored configuration) |
Electrical Specifications
|
Parameter |
Value |
|---|---|
|
Scale Factor |
7.87 V/mm (200 mV/mil) ±6.5% |
|
Linear Range |
2 mm (80 mils) |
|
Recommended Gap |
1.27 mm (50 mils) |
|
Probe Resistance (2.0 m) |
7.88 Ω ±0.5 |
|
Output Resistance |
50 Ω |
Environmental Limits
|
Parameter |
Value |
|---|---|
|
Probe Temperature Range |
-35°C to +177°C (-31°F to +351°F) |
|
Extension Cable Temperature Range |
-51°C to +177°C (-60°F to +351°F) |
|
Minimum Cable Bend Radius |
25.4 mm (1.0 in) |
|
Probe Pressure Seal |
Fluorocarbon O-ring |
Compliance and Certifications
|
Certification |
Details |
|---|---|
|
EMC |
EN 61000-6-2, EN 61000-6-4, EMC Directive 2014/30/EU |
|
ATEX/IECEx Approval |
Ex ia IIC T5…T1 Ga; Ex nA IIC T5…T1 Gc |
|
RoHS |
Compliant (Directive 2011/65/EU) |
|
FCC |
Part 15 compliant |
