Bently Nevada 3300/03-01-02 Interface Module
Bently Nevada 3300/03-01-02 Interface Module
Manufacturer: Bently Nevada
Product No.: 3300/03-01-02
Condition:1000 in stock
Product Type: Vibration Monitors
Product Origin: 003300030102
Payment: T/T, Western Union
Weight: 200g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Bently Nevada 3300/03-01-02 Dual Vibration Monitor Interface Module
The Bently Nevada 3300/03-01-02 is a precision interface module designed for the 3300 series vibration monitoring system. This dual-channel module processes signals from proximity probes and seismic sensors, providing critical machinery health data for turbines, compressors, and rotating equipment in power generation, oil & gas, and manufacturing industries.
Key Features
- ✅ Dual Channel Processing – Monitor two measurement points simultaneously
- ✅ Universal Input – Compatible with proximity probes and accelerometers
- ✅ Programmable Alarms – Configurable alert and danger setpoints
- ✅ 4-20mA Output – Industry-standard analog output for DCS/PLC integration
- ✅ API 670 Compliant – Meets machinery protection system standards
- ✅ Hot-Swappable – Replace modules without system shutdown
Technical Specifications
| Part Number | 3300/03-01-02 |
| Product Type | Dual Vibration Monitor Interface Module |
| Channels | 2 independent monitoring channels |
| Input Types | Proximity probes, accelerometers, velocity sensors |
| Output Signal | 4-20mA (isolated) |
| Alarm Relays | 2 per channel (Alert, Danger) |
| Power Supply | 24V DC (18-30V range) |
| Operating Temp | -30°C to +65°C |
| Mounting | DIN rail or panel mount |
| Certifications | API 670, CE, UL, CSA |
| Dimensions | Standard 3300 series module size |
| Weight | Approx. 500g |
System Integration
Compatible Sensors
- Proximity Probes: 3300 XL 8mm, 11mm series
- Accelerometers: 330400, 330425 series
- Velocity Sensors: 330500 series
- Keyphasor: 330500-02-00 for phase reference
Output Connections
- Analog Output: 4-20mA to DCS, PLC, or SCADA systems
- Relay Outputs: Alarm contacts for machinery shutdown systems
- Digital Communication: Modbus RTU (optional)
Industrial Applications
Steam & Gas Turbines
Monitor bearing vibration and shaft displacement in power generation turbines. Dual channels enable simultaneous X-Y radial vibration measurement for orbit analysis.
Centrifugal Compressors
Protect critical compressor trains in oil & gas facilities. API 670 compliance ensures machinery protection system certification.
Large Motors & Generators
Track rotor vibration in electric motors and generators above 1,000 HP. Early fault detection prevents catastrophic bearing failures.
Pumps & Fans
Monitor vibration in critical process pumps and induced draft fans. Reduce unplanned maintenance and extend equipment life.
Installation & Configuration
Mounting Options
- DIN Rail Mount – Snap module onto standard 35mm DIN rail in control cabinet
- Panel Mount – Use mounting brackets for direct panel installation
- Rack Mount – Install in 3300 series monitoring rack (requires rack chassis)
Configuration Steps
- Connect proximity probes or accelerometers to input terminals
- Set measurement range using DIP switches or software configuration
- Program alarm setpoints (Alert and Danger levels)
- Connect 4-20mA output to DCS/PLC analog input
- Wire relay contacts to machinery shutdown system
- Apply 24V DC power and verify LED indicators
- Calibrate using known vibration source or signal generator
Alarm Configuration
Two-Stage Alarm System
- Alert Level: Early warning of abnormal vibration (typically 70% of trip level)
- Danger Level: Critical alarm triggers machinery shutdown (API 670 trip level)
Typical Setpoints (ISO 10816)
| Machine Type | Alert (mm/s RMS) | Danger (mm/s RMS) |
|---|---|---|
| Small machines (<15 kW) | 4.5 | 7.1 |
| Medium machines (15-75 kW) | 7.1 | 11.2 |
| Large machines (>75 kW) | 11.2 | 18.0 |
| Turbines (rigid foundation) | 7.1 | 11.2 |
Troubleshooting
| Problem | Cause | Solution |
|---|---|---|
| No output signal | Sensor disconnected | Check sensor wiring, verify continuity |
| Erratic readings | Electrical noise | Verify grounding, separate from power cables |
| Alarm relay stuck | Relay failure | Replace module or use alternate relay output |
| 4-20mA output incorrect | Calibration drift | Recalibrate using signal generator |
Authenticity Guarantee
⚠️ Counterfeit Module Risks
Non-genuine interface modules can cause:
- ❌ Inaccurate vibration measurements leading to missed faults
- ❌ False alarms causing unnecessary shutdowns
- ❌ Non-compliance with API 670 standards
- ❌ Voided machinery protection system certifications
✅ Industrial Control Hub Guarantee
- 🔒 100% Genuine Bently Nevada – Factory-sealed packaging
- 📜 Full Traceability – Serial numbers and certificates
- 🌍 Authorized Distributor – Verify at Baker Hughes partner portal
- 🛡️ 24-Month Warranty – Manufacturer warranty honored globally
- 📦 ESD Protection – Anti-static packaging prevents damage
Package Contents
- 1× Bently Nevada 3300/03-01-02 interface module
- Installation manual and configuration guide
- Mounting hardware (DIN rail clips or panel brackets)
- Terminal block connectors
Related Products
- Proximity Probes: 3300 XL 8mm (330180-90-00)
- Accelerometers: 330400-01-00 (general purpose)
- Extension Cables: 330130 series (various lengths)
- Power Supply: 24V DC DIN rail mount
Technical Support
- 📧 Application Engineering – Email us for sensor selection and alarm setpoint recommendations
- 📚 Documentation – Installation manuals, API 670 guides, calibration procedures
- 🎓 Training Resources – Vibration monitoring fundamentals and troubleshooting
- 🔧 Commissioning Support – Remote assistance for initial setup and calibration
- 🔄 30-Day Returns – Unused modules in original packaging
FAQ
Q: What is the difference between 3300/03 and 3300/05 modules?
A: 3300/03 is a dual-channel monitor. 3300/05 is a single-channel monitor with additional features.
Q: Can I use this module with non-Bently Nevada sensors?
A: Not recommended. Module is calibrated for Bently Nevada sensor specifications.
Q: How often should I recalibrate the module?
A: API 670 recommends annual calibration verification. Full recalibration every 3-5 years.
Q: Can I hot-swap this module?
A: Yes, if installed in a 3300 series rack with redundant power. Standalone installations require shutdown.
