Product Description
Bently Nevada 149776-01 Parameters
Product Overview
| Parameter | Details |
|---|---|
| Manufacturer | Bently Nevada |
| Series | Trendmaster DSM |
| Model/Part Number | 149776-01 |
| Model Type | Ethernet Communication Card |
| Product Name | 10/100BaseT Ethernet Communication Card |
| Application | High-speed Ethernet communication for Trendmaster DSM racks in machinery condition monitoring systems |
| Compatibility | Fits Trendmaster DSM racks; integrates with System 1 Classic 6.X and System 1 Evo 20.1+ platforms |
| Function | Enables fast data exchange using TCP/IP and Modbus over TCP/IP protocols |
Functional Specifications
| Parameter | Details |
|---|---|
| Ethernet Support | 10/100BaseT auto-negotiating |
| Protocols | TCP/IP UDP for initialization, Modbus over TCP/IP (up to 6 clients) |
| Response Time | 0.5 sec |
| Baud Rate | 10 Base T or 100 Base TX |
| Cable Length | 100 meters (328 feet), Category 5 twisted pair |
| Connector Type | RJ45 |
| Status LED | Tri-color LED indicates status of DSM and input modules with combinations of colors and flash rates |
| Link/Activity LED | Tri-color LED indicates network link status |
