Product Description
Product Overview
- The Bently Nevada 136634-0010-01 Transducer Interface Module connects proximity transducers to the Bently Nevada 3300 Series Machinery Protection System for vibration, position, or speed monitoring in rotating machinery, such as turbines, compressors, and pumps, across power generation, oil and gas, and industrial sectors
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Bently Nevada |
| Series | 3300 Series |
| Model/Part Number | 136634-0010-01 |
| Model Type | Transducer Interface Module |
| Function | Connects proximity transducers to 3300 Series monitoring modules for vibration, position, or speed monitoring |
| Processor | Not applicable (performs passive signal conditioning) |
| Memory | Not applicable |
| Display | None (no indicators; connected 3300 monitor displays status) |
| Inputs | 1 transducer input (works with Bently Nevada proximity probes, such as 3300 XL 8 mm, 5 mm, or 11 mm) |
| Outputs | 1 conditioned signal output (to 3300 Series monitor modules, like 3300/16, 3300/20) 1 buffered transducer output (for external diagnostics) |
| Communication Interfaces | None (connects directly to 3300 monitor via proprietary wiring) |
| Signal Conditioning | Supplies power to proximity probe (-24 VDC), linearizes, and conditions transducer signal for monitor input |
| Frequency Range | 0–10 kHz (suitable for vibration and speed signals) |
| Accuracy | ±1% of full-scale range (with compatible transducer and monitor) |
| Redundancy | Non-redundant |
| Diagnostics | Monitors signal integrity (connected 3300 monitor handles diagnostics) |
| Compatibility | Works with Bently Nevada 3300 Series monitors, like 3300/16, 3300/20, 3300/30, and proximity probes, such as 3300 XL 8 mm, 5 mm, 11 mm; offers limited compatibility with 3500 Series via adapters; integrates with System 1 software via 3300 rack interface |
| Power Supply | Receives power via 3300 rack backplane (-24 VDC for transducer, supplied by monitor) |
| Power Consumption | Approximately 1–2 W (varies with transducer) |
| Environmental Specifications | Operating Temperature: -30°C to +65°C (-22°F to +149°F) Storage Temperature: -40°C to +85°C (-40°F to +185°F) Relative Humidity: 5% to 95% non-condensing Vibration: Complies with IEC 60068-2-6 Shock: Complies with IEC 60068-2-27 |
| Enclosure | IP20 (installs in 3300 Series rack or enclosure) |
| Dimensions | Approximately 100 mm (H) x 50 mm (W) x 75 mm (D, varies by configuration) |
| Weight | Approximately 0.2–0.4 kg |
| Mounting | Plugs into 3300 Series rack or connects via terminal block in enclosure |
| Certifications | Meets CE, CSA, ATEX/IECEx Zone 2 (in approved enclosure), and marine certifications, such as DNV, ABS (configuration-specific) |
