Product Description
Bently Nevada 121M6469-02 Parameters
Product Overview
| Parameter | Details |
|---|---|
| Manufacturer | Bently Nevada |
| Series | Ranger Pro |
| Model/Part Number | 121M6469-02 |
| Model Type | Wireless Triaxial Vibration Sensor |
| Product Name | Ranger Pro Wireless Triaxial Vibration and Temperature Sensor |
| Application | Rotating machinery monitoring for predictive maintenance in industrial applications such as petrochemical, refining, and power generation |
| Compatibility | ISA100.11a gateways including Bently Nevada 70M320, Yokogawa YFGW410/510, Honeywell WDM; integrates with System 1 software |
| Function | Continuously measures triaxial vibration and temperature, transmits data wirelessly for real-time condition monitoring |
Functional Specifications
| Parameter | Details |
|---|---|
| Wireless Standard | ISA100.11a compliant |
| Measurement Capabilities | Triaxial vibration (RMS, peak, peak-to-peak) and temperature |
| Power Supply | Battery-powered (replaceable lithium-thionyl chloride) |
| Battery Life | Up to 5 years depending on configuration and update rate |
| Environmental Rating | IP67, suitable for hazardous areas |
| Operating Temperature | -40°C to +80°C |
| Frequency Range | 0.5 Hz to 10 kHz |
| Dynamic Range | 80 dB |
| Gateway Support | Up to 50 devices per gateway |
| Certifications | FCC Part 15, KCC, ATEX/IECEx for hazardous locations |
