Product Description
General Information
|
Field |
Details |
|---|---|
|
Manufacturer |
BACHMANN |
|
Model/Part Number |
EM213 / EM213 CC |
|
Model Type |
Industrial Ethernet Master Module |
Description
The EM213 module is an Industrial Ethernet Master that extends the BACHMANN control system by adding an additional Ethernet interface with three 10/100 MBit RJ45 ports. It includes an integrated switch and enables Ethernet-based networking or service laptop connectivity, especially for FASTBUS SubDevices.
Key Features
-
3x RJ45 Ethernet ports (10/100BaseT, auto-cross detection)
-
Cable length: Up to 100 m per line
-
Integrated switch
-
LED status indicators:
-
Power
-
Collision
-
4x LinkPuls
-
3x Speed indicators (10/100 Mbit/s)
-
Data rate to M200 CPU: Up to 2.4 Mbit/s user data
-
Transmission rate as switch: Up to 100 Mbit/s
-
Line impedance: 100 Ω
Environmental Specifications
|
Parameter |
Standard / ColdClimate Models |
|---|---|
|
Operating Temperature |
-30 °C to +60 °C |
|
Storage Temperature |
-40 °C to +85 °C |
|
Relative Humidity (Operation) |
5 % to 95 %, non-condensing / with condensation |
|
Relative Humidity (Storage) |
5 % to 95 %, non-condensing / with condensation |
|
Pollution Degree |
2 (per IEC 60664-1) |
Approvals / Certificates
|
Type |
Certifications |
|---|---|
|
General |
CE, UKCA, cULus |
|
Marine |
ABS, BV, DNV, KR, LR, NK, RINA |
Ordering Information
|
Part Type Designation |
Part Number |
Description |
|---|---|---|
|
EM213 |
00017321-00 |
Ethernet interface module; RJ45; 3 ports; Eth100 |
|
EM213 CC |
00017470-00 |
Same as EM213; ColdClimate version |
