Product Description
General Information
|
Manufacturer |
BACHMANN |
|---|---|
|
Model/Part Number |
DF915 DKT |
|
Series |
DF900 |
|
Description |
Headless IPCs and remote displays |
Display Specifications
|
Model |
Diagonal / Resolution |
Display Type |
Brightness |
Half-Brightness Lifetime |
|---|---|---|---|---|
|
DF915 |
15” XGA (1024x768) |
Color TFT |
300 cd/m² |
≥ 50,000 h |
|
DF919 |
19” SXGA (1280x1024) |
Color TFT |
300 cd/m² |
≥ 50,000 h |
Control & Interface Features
|
Touch Screen Type |
Front Keyboard |
System LEDs |
|---|---|---|
|
Analog resistive |
Optional / Max. 128 keys, 2-fold programmable |
Power, DIAG |
|
Interfaces |
|
|---|---|
|
USB |
2x USB (rear) |
|
CAN |
1x CAN (rear) |
Power & Environmental Specifications
|
Power Supply |
24 V DC (18 V .. 36 V) |
|---|---|
|
Operating Temperature |
0 °C .. +50 °C (fan-free), limited to +45 °C in fan-free operation |
Physical & Regulatory
|
Housing Material |
Aluminum |
|---|---|
|
Front Protection |
IP65 |
|
Rear Protection |
IP20 |
|
Certifications |
CE, UL, CUL |
