Bachmann BS210 Backplane
Bachmann BS210 Backplane
Manufacturer: Bachmann
Product No.: BS210
Condition:1000 in stock
Product Type: Backplane
Product Origin: Austria
Payment: T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Bachmann BS210 Backplane
Product Overview
- The Bachmann BS210 is a backplane module designed for use in Bachmann__ modular automation systems, specifically for industrial control applications such as wind turbines, power generation, manufacturing, and process automation. Part of the Bachmann M1 controller system
Technical Specifications
- The BS210 has the following specifications based on industry sources and Bachmann documentation:
| Specification | Details |
|---|---|
| Model/Part Number | BS210 |
| Manufacturer | Bachmann electronic GmbH |
| Description | 10-Slot Backplane for M1 Controller System |
| Series | M1 Controller System |
| Function | Provides mechanical and electrical connectivity for I/O, CPU, and communication modules |
| Slot Capacity | 10 slots for M1 modules (e.g., CPU, I/O, communication) |
| Bus System | High-speed Bachmann M1 system bus (proprietary, up to 100 Mbps) |
| Power Supply | 24 VDC (via external power supply module, e.g., NT255) Optional redundant power supply |
| Power Distribution | 5 VDC and 24 VDC to connected modules (max. 10 A per rail) |
| Connectors | High-density backplane connectors (DIN 41612 compliant) |
| Communication | Supports M1 system bus for inter-module communication; no direct external interfaces |
| Redundancy | Supports redundant CPU and power supply configurations (with compatible modules) |
| Diagnostics | LED indicators for power, bus status, and fault detection; diagnostics via CPU module |
| Compatibility | Bachmann M1 modules (e.g., MX213, MPC270, DIO280, AIO208, CM202); power supply modules (e.g., NT255); integrates with Bachmann software (e.g., M-BASE, SolutionCenter) |
| Environmental Specifications | Operating Temperature: -30°C to +60°C (-22°F to +140°F) Storage Temperature: -40°C to +85°C (-40°F to +185°F) Relative Humidity: 5% to 95% non-condensing Vibration: EN 60068-2-6 compliant Shock: EN 60068-2-27 compliant |
| Enclosure | IP20 (requires enclosure for harsh environments) |
| Dimensions | Approx. 482.6 mm (W) x 132.5 mm (H) x 50 mm (D) (19-inch rack, 3U height) |
| Weight | Approx. 1.5_2 kg (without modules) |
| Mounting | 19-inch rack or panel-mounted (standard DIN rail or direct mounting) |
| Certifications | CE, UL, CSA, marine certifications (e.g., DNV, ABS, configuration-dependent); ATEX/IECEx Zone 2 (optional)_ |
