Bachmann B2565/00 Digital I/O Module
Product Overview
- The Bachmann B2565/00 is a Digital Input/Output (I/O) Module designed by Bachmann electronic GmbH for use in their M1 automation system. This module is engineered to interface with digital signals, enabling the monitoring and control of binary states (on/off) in industrial automation applications. It is commonly used in industries such as manufacturing, energy, process control, and renewable energy (e.g., wind turbines) to manage devices like switches, relays, sensors, and actuators.
Technical Specifications
- The B2565/00 has the following specifications
| Specification | Details |
|---|---|
| Model/Part Number | B2565/00 |
| Manufacturer | Bachmann electronic GmbH |
| Description | Digital Input/Output Module |
| Series | Bachmann M1 Automation System |
| Function | Processes digital input signals and controls digital output signals |
| Channels | Typically 16 digital inputs and 16 digital outputs (configuration-dependent) |
| Input Voltage | 24 VDC nominal (typically 0–30 VDC range) |
| Input Type | Sinking or sourcing (configuration-dependent) |
| Output Type | Transistor outputs (sourcing, typically 24 VDC) |
| Output Current | Up to 0.5 A per channel (max, short-circuit protected) |
| Response Time | <1 ms (typical for input/output processing) |
| Isolation | Galvanic isolation between channels and backplane (500 VDC) |
| Communication | Interfaces with M1 system via backplane (proprietary M1 bus) |
| Power Supply | 24 VDC (supplied via M1 system backplane) |
| Power Consumption | Approx. 3–6 W (depending on load) |
| Environmental Specifications | Operating Temperature: -30°C to +60°C Storage Temperature: -40°C to +85°C Relative Humidity: 5% to 95% non-condensing Vibration: IEC 60068-2-6 compliant Shock: IEC 60068-2-27 compliant |
| Dimensions | Approx. 120 mm (H) x 50 mm (W) x 160 mm (D) (standard M1 module size) |
| Weight | Approx. 0.3–0.5 kg |
| Mounting | DIN rail or backplane mounting within M1 system |
| Certifications | CE, UL, DNV GL (suitable for industrial and marine applications) |
