Product Description
Bachmann AINT-24V Analog Input Module
Product Overview
- The Bachmann AINT-24V is an Analog Input Module designed by Bachmann electronic GmbH for use in their M1 automation system. This module is engineered to interface with analog sensors and devices, converting analog signals (such as voltage or current) into digital data for processing within industrial automation applications. It is commonly used in industries like manufacturing, energy, and process control, including wind turbine systems, to monitor parameters such as temperature, pressure, or flow.
Technical Specifications
- The AINT-24V has the following specifications
| Specification | Details |
|---|---|
| Model/Part Number | AINT-24V |
| Manufacturer | Bachmann electronic GmbH |
| Description | Analog Input Module |
| Series | Bachmann M1 Automation System |
| Function | Converts analog signals (voltage/current) to digital data for M1 system processing |
| Input Channels | Typically 8 analog inputs (configuration-dependent) |
| Input Signal Types | 0–10 V, ±10 V, 0–20 mA, 4–20 mA (configurable per channel) |
| Resolution | 16-bit A/D conversion |
| Accuracy | ±0.1% of full scale (typical) |
| Sampling Rate | Up to 1 kHz per channel (configuration-dependent) |
| Input Impedance | >1 MΩ (voltage inputs), ~250 Ω (current inputs) |
| Communication | Interfaces with M1 system via backplane (proprietary M1 bus) |
| Power Supply | 24 VDC (supplied via M1 system backplane) |
| Power Consumption | Approx. 3–5 W |
| Environmental Specifications | Operating Temperature: -30°C to +60°C Storage Temperature: -40°C to +85°C Relative Humidity: 5% to 95% non-condensing Vibration: IEC 60068-2-6 compliant Shock: IEC 60068-2-27 compliant |
| Dimensions | Approx. 120 mm (H) x 50 mm (W) x 160 mm (D) (standard M1 module size) |
| Weight | Approx. 0.3–0.5 kg |
| Mounting | DIN rail or backplane mounting within M1 system |
| Certifications | CE, UL, DNV GL (suitable for industrial and marine applications) |
