ABB ANK31 Analog Input/Output Module
Product Overview
- The ABB ANK31 is an Analog Input/Output Module designed for use in ABB’s Advant OCS (Open Control System) or Master systems, particularly within distributed control systems (DCS) for industrial automation. This module facilitates the acquisition and processing of analog signals from field devices (e.g., sensors, transmitters) and provides analog outputs to actuators or other devices. It is commonly used in industries such as power generation, oil and gas, chemical processing, and pulp and paper for precise process control and monitoring. The ANK31 is known for its reliability, flexibility, and compatibility with ABB’s legacy automation platforms.
Technical Specifications
- The ANK31 has the following specifications based on industry sources and ABB documentation:
| Specification | Details |
|---|---|
| Model/Part Number | ANK31 |
| Manufacturer | ABB |
| Description | Analog Input/Output Module for Advant OCS/Master Systems |
| Series | Advant OCS, Master |
| Function | Acquires analog inputs and provides analog outputs for process control |
| Input Channels | 8 analog inputs (configuration-dependent) |
| Output Channels | 4 analog outputs (configuration-dependent) |
| Input Signal Types | Current: 0/4–20 mA Voltage: 0–10 V, ±10 V Thermocouples or RTDs (with external adapters) |
| Output Signal Types | Current: 0/4–20 mA Voltage: 0–10 V |
| Resolution | 12 bit (typical) |
| Accuracy | ±0.1% of full scale (typical) |
| Conversion Time | Approx. 10–20 ms per channel (configuration-dependent) |
| Isolation | Galvanic isolation between channels and system bus |
| Diagnostics | Wire break, short circuit, overrange/underrange detection |
| Communication | Via Advant Fieldbus or MasterBus (through controller) |
| Compatibility | ABB Advant OCS, MasterPiece controllers, Advant Controller 450 |
| Power Supply | 24 VDC (via system backplane) |
| Power Consumption | Approx. 5–7 W |
| Environmental Specifications | Operating Temperature: 0°C to +55°C (32°F to +131°F) Storage Temperature: -25°C to +70°C (-13°F to +158°F) Relative Humidity: 5% to 95% non-condensing Vibration: IEC 60068-2-6 compliant |
| Enclosure | IP20 (installed in control cabinet) |
| Dimensions | Approx. 150 mm (H) x 50 mm (W) x 120 mm (D) |
| Weight | Approx. 0.4–0.6 kg |
| Mounting | Plugs into Advant OCS/Master system rack |
| Certifications | CE, UL, CSA, complies with IEC 61131 standards |
