Allen-Bradley PLC-5 1771-OYL Point Digital Output Module

Allen-Bradley PLC-5 1771-OYL Point Digital Output Module

  • Manufacturer: Allen-Bradley

  • Product No.: 1771-OYL

  • Condition:1000 in stock

  • Product Type: Point Digital Output Module

  • Product Origin: USA

  • Payment: T/T, Western Union

  • Weight: 1000g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

Product Details:

  • Manufacturer: Allen-Bradley
  • Model/Part Number: PLC-5 1771-OYL
  • Description: Point Digital Output Module

Specifications:

Attribute Value
Outputs per Module 8 (4 groups of 2)
Module Location 1771 I/O chassis
Contact Configuration 4 Form A (N.O.), 4 Form B (N.C.)
Voltage Rating 0-24V AC (rms); 0-24V DC
Current Rating 100mA per output (maximum)
Surge Current 100mA maximum per output (at rated power)
Power Rating DC: 2.4W per output (resistive); AC (suppressed): 2.4W per output (resistive)
Minimum Contact Load DC: 1mA @ 0-24V AC; AC: 1mA @ 0-24V
Operate/Release Time 1ms (maximum)
Bounce Time 1ms (maximum)
Switching Frequency 10Hz (maximum)
Power Dissipation 2.2 Watts (maximum); 2 Watts (minimum)
Thermal Dissipation 7.6 BTU/hr (maximum); 6.9 BTU/hr (minimum)
Backplane Current 420mA maximum
Isolation Voltage 1000V between open contacts; 1500V between coil and contact
Conductors / Wire Size 14 gauge (2mm²) stranded (maximum); 3/64 inch (1.2mm) insulation (maximum)
Environmental Conditions Operating Temperature: 0°C to 60°C (32°F to 140°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Relative Humidity: 5% to 95% (without condensation)
Keying Between 6 and 8
Field Wiring Arm Catalog Number 1771-WD
Wiring Arm Screw Torque 7-9 inch-pounds
Agency Certification CSA certified, CSA Class I, Division 2, Groups A, B, C, D certified, UL listed, CE marked for all applicable directives
Installation Data Number 1771-2.184
