Allen-Bradley 1769-IF4X0F2 Analog I/O Module | 6-Channel CompactLogix Combination

🔧 Allen-Bradley 1769-IF4X0F2 CompactLogix Analog I/O Combination Module

The 1769-IF4X0F2 delivers precision analog signal processing for CompactLogix control systems, combining four configurable input channels and two flexible output channels in a single compact footprint. Engineered for demanding industrial environments, this module bridges the gap between field instrumentation and your control architecture.

⚙️ Technical Specifications

• Input Channels: 4 differential analog inputs (voltage/current configurable)
• Output Channels: 2 analog outputs (voltage/current selectable)
• Resolution: 16-bit for superior measurement accuracy
• Input Ranges: ±10V DC, 0-10V DC, 0-20mA, 4-20mA
• Output Ranges: ±10V DC, 0-10V DC, 0-20mA, 4-20mA
• Update Time: 10ms typical per channel
• Isolation: Channel-to-backplane isolation for noise immunity
• Power Consumption: 1.5W @ 5V DC from backplane

🏭 Application Scenarios

Process Control: Monitor temperature, pressure, and flow transmitters while controlling valve positioners and variable frequency drives in chemical processing, water treatment, and HVAC systems.

Machine Automation: Interface with load cells, strain gauges, and position sensors for packaging lines, material handling, and assembly operations requiring closed-loop feedback.

Energy Management: Acquire data from power meters, environmental sensors, and building automation devices while outputting setpoints to actuators and dampers.

✅ Solution Advantages

✓ Space Optimization: Consolidates six I/O points in one module, reducing chassis slot requirements by 50% compared to separate input/output modules
✓ Flexible Configuration: Software-selectable ranges eliminate the need for multiple spare parts inventory
✓ Diagnostic Intelligence: Built-in channel health monitoring and open-wire detection accelerate troubleshooting
✓ Seamless Integration: Native RSLogix 5000/Studio 5000 support with pre-built Add-On Instructions (AOIs) for rapid commissioning

📦 What's Included

• 1769-IF4X0F2 Analog Combination Module
• Removable terminal block (RTB) with screw terminals
• Installation and wiring documentation

🔌 System Compatibility

Compatible with all CompactLogix 1769 chassis and controllers including L1, L2, L3, and L4 series. Requires RSLogix 5000 v16 or later / Studio 5000 Logix Designer v21 or later for configuration.

Upgrade your analog I/O infrastructure with proven Allen-Bradley reliability and performance. Ideal for retrofits, expansions, and new installations across manufacturing, infrastructure, and process industries.
