Allen-Bradley 1761-L10BWA MicroLogix 1000 Programmable Controllers

Allen-Bradley 1761-L10BWA MicroLogix 1000 Programmable Controllers

  • Manufacturer: Allen-Bradley

  • Product No.: 1761-L10BWA

  • Condition:1000 in stock

  • Product Type: MicroLogix 1000 Programmable Controllers

  • Product Origin: USA

  • Payment: T/T, Western Union

  • Weight: 1000g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

Product Details: Allen-Bradley MicroLogix 1000 Programmable Controller (Model: 1761-L10BWA)


General Overview

  • Manufacturer: Allen-Bradley
  • Model/Part Number: 1761-L10BWA
  • Description: The MicroLogix 1000 Programmable Controller is a compact and cost-effective solution for small control applications. It features built-in memory, versatile power supply options, and robust environmental tolerance for industrial use.

Physical Dimensions

Dimension Value
Length 120 mm (4.72 in.)
Depth 73 mm (2.87 in.)
Height 80 mm (3.15 in.)

Memory and Power Specifications

Feature Specification
Memory Size/Type 1 K EEPROM (737 instruction words, 437 data words)
Power Supply Voltage 85-264V AC (47-63 Hz), 20.4-26.4V DC
Power Supply Usage AC (120V): 15 VA - 29 VA
AC (240V): 21 VA - 36 VA
DC (24V): 5W - 7W
Max Inrush Current 30A for 8 ms (AC), 30A for 4 ms (DC)
Sensor Power Output 24V DC at 200 mA, 200 µF max capacitive load

Environmental Specifications

Feature Specification
Operating Temperature Refer to environmental limits for variations
Vibration Operating: 5 Hz to 2 kHz, 0.381 mm peak-to-peak/2.5g (panel-mounted)
Non-operating: 5 Hz to 2 kHz, 0.762 mm peak-to-peak/5g
Shock Operating: 10g peak acceleration (7.5g DIN rail-mounted)
Non-operating: 20g peak acceleration
Electrostatic Discharge EN 61000-2, up to 8 kV
Radiated Susceptibility EN 61000-3, up to 10 V/m
Fast Transient Immunity EN 61000-4, 2 kV for power supply/I/O; 1 kV for communication lines
Isolation Voltage 1500V AC

Terminal and Mounting Details

Feature Specification
Terminal Screw Torque Maximum 0.9 N-m (8.0 in.-lbs)
Mounting Options Panel-mounted (1g vibration) or DIN rail-mounted (shock considerations apply)

Key Features

  • Compact Design: Ideal for small-scale control applications where space is limited.
  • Robust Environmental Tolerance: Built to withstand industrial conditions, including temperature extremes, high humidity, and mechanical shock/vibration.
  • Flexible Power Options: Compatible with both AC and DC power supplies.
  • Advanced Electromagnetic Compliance: Meets EN standards for electrostatic discharge, radiated susceptibility, and fast transient immunity.
  • High-Quality Construction: Durable materials and reliable operation ensure long-term performance in demanding environments.
