| Cable Type |
Redundant power supply cable |
| Connector Type |
10-pin connector for power supply to chassis |
| Cable Length |
0.91 m (3 ft) |
| Wire Size |
2.5 mm² (14 AWG) |
| Voltage Rating |
30 V DC maximum |
| Current Rating |
20 A maximum per cable |
| Isolation |
None (direct connection between power supply and chassis) |
| Operating Temperature |
0°C to 60°C (32°F to 140°F) |
| Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
| Humidity |
5% to 95% (non-condensing) |
| Weight |
0.2 kg (0.44 lb) |
| Standards Compliance |
CE, UL, CSA (Class I, Div 2, Groups A, B, C, D) |
