Product Description
Product Overview
| Parameter | Details |
|---|---|
| Part Number | 1756-BATA |
| Product Name | ControlLogix Lithium Battery Assembly |
| Application | Backup power for ControlLogix controller memory |
| Compatibility | Compatible with 1756-L6x controllers (Series B) |
| Function | Provides non-rechargeable backup power for volatile memory |
Functional Specifications
| Parameter | Details |
|---|---|
| Battery Type | Lithium, non-rechargeable |
| Nominal Voltage | 3 V DC |
| Capacity | 1200 mAh |
| Storage Temperature | -45°C to 30°C (-49°F to 86°F) |
| Storage Humidity | Up to 30% relative humidity |
| Storage Duration | Up to 10 years from manufacture date |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Installation Requirement | Must be installed/replaced in non-hazardous area |
| Weight | Approximately 0.017 kg (0.037 lb) |
| Standards Compliance | CE, UL, CSA (Class I, Div 2, Groups A, B, C, D) |
Safety and Handling
| Parameter | Details |
|---|---|
| Safety Considerations | Do not recharge, open, puncture, crush, incinerate, expose to high temperatures (>30°C/86°F for >30 days), solder leads, or short terminals |
| Transport | Comply with national/international regulations; |
| Disposal | Collect separately from municipal waste, avoid incineration or general waste disposal, comply with local regulations |
| Hazards | Risk of burns, explosion, fire, or exposure to toxic/corrosive materials if mishandled |
