Product Description
🔹 General Information
|
Manufacturer |
Allen-Bradley |
|---|---|
|
Model/Part Number |
1734-IK |
|
Description |
POINT I/O Module |
🔹 General Specifications
|
Attribute |
Value |
|---|---|
|
Terminal Base Screw Torque |
0.6 N•m (7 lb•in) |
|
Module Location |
1734-TB, 1734-TBS, 1734-TB3, 1734-TB3S wiring base assembly |
|
POINTBus™ Current (Max) |
160 mA |
|
Power Dissipation (Max @ Rated Load) |
1.1 W |
|
Thermal Dissipation (Max @ Rated Load) |
3.75 BTU/hr |
|
Isolation Voltage (Continuous-Voltage Withstand Rating) |
50V type |
|
Tested Voltage |
Tested @ 1100V DC for 60 s, field-side to system |
|
External DC Power |
No additional external power required |
|
Dimensions (HxWxD) |
56.0 x 12.0 x 75.5 mm (2.21 x 0.47 x 2.97 in.) |
|
Wiring Category |
1 – on signal ports |
|
Wire Size |
0.25…2.5 mm² (22…14 AWG) solid or stranded copper wire rated at 75 °C (167 °F), or greater, 1.2 mm (3/64 in.) insulation max |
|
Weight, Approx. |
0.36 kg (0.08 lb) |
|
Keyswitch Position |
2 |
|
Enclosure Type Rating |
None (open-style) |
|
North American Temp Code |
T4A |
|
UKEX/ATEX Temp Code |
T4 |
|
IECEx Temp Code |
T4 |
🔹 Environmental Specifications
|
Attribute |
Value |
|---|---|
|
Temperature (Operating) |
-20 °C to +55 °C (-4 °F to +131 °F) |
|
Temperature (Non-operating) |
-40 °C to +85 °C (-40 °F to +185 °F) |
|
Temperature (Surrounding Air, Max) |
55 °C (131 °F) |
|
Relative Humidity |
5…95% non-condensing |
|
Vibration |
5 g @ 10…500 Hz (IEC 60068-2-6, Test Fc, operating) |
