ABB UFC765AE102 Circuit Board 3BHE003604R0102 ACS 600 Series

Manufacturer: ABB
Product No.: 3BHE003604R0102
Condition:1000 in stock
Product Type: Circuit Board
Product Origin: 8502345678901
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months

Quantity

24/7 Support
30-Day Returns
Fast Shipping

ABB UFC765AE102 Industrial Circuit Board - ACS 600 Series Control Module

The ABB UFC765AE102 (Part Number: 3BHE003604R0102) is a precision-engineered circuit board designed for the ACS 600 series variable frequency drives. This control module delivers exceptional performance in AC motor control applications, providing reliable frequency conversion and motor management for industrial automation systems.

Key Technical Parameters

Part Number: 3BHE003604R0102
Model: UFC765AE102
Series: ACS 600 Variable Frequency Drive
Output Frequency Range: 0-2000 Hz
Control Type: Advanced vector control with sensorless operation
Communication: Multiple fieldbus protocol support
Operating Temperature: -10°C to +50°C ambient
Protection Rating: Industrial-grade environmental protection

Industrial Applications

This circuit board excels in demanding motor control environments including manufacturing automation, material handling conveyors, HVAC systems, pump and fan control, textile machinery, and process industry applications. The wide frequency range enables precise speed control for specialized applications requiring ultra-high-speed motor operation or micro-stepping capabilities.

Engineering Advantages

The UFC765AE102 integrates advanced control algorithms that optimize motor efficiency while reducing energy consumption. Built-in protection features include overcurrent detection, thermal monitoring, and fault diagnostics with comprehensive alarm logging. The modular design facilitates rapid replacement during maintenance, minimizing production downtime and reducing total cost of ownership.

Frequently Asked Questions

Q: Is this board compatible with all ACS 600 drive models?
A: The UFC765AE102 is designed for specific ACS 600 configurations. Verify compatibility using the complete part number 3BHE003604R0102 against your drive documentation.

Q: What diagnostic capabilities does this board provide?
A: The board features comprehensive fault logging, real-time parameter monitoring, and communication status indicators for efficient troubleshooting.

Q: Can this board be repaired if damaged?
A: Due to the complexity of modern control electronics, replacement is typically more cost-effective than repair. We recommend maintaining spare inventory for critical applications.

Quality Assurance & Support

Every ABB UFC765AE102 circuit board undergoes stringent quality testing to ensure compliance with industrial standards. Covered by a comprehensive 12-month warranty against manufacturing defects, providing confidence for mission-critical installations.
