ABB PM585-ETH 1SAP140500R0271 AC500 Processor Module

ABB PM585-ETH 1SAP140500R0271 AC500 Processor Module with Ethernet

The ABB PM585-ETH 1SAP140500R0271 AC500 Processor Module delivers high-performance programmable logic control for scalable industrial automation applications. Featuring integrated Ethernet connectivity, robust processing power, and IEC 61131-3 compliant programming, this modular PLC processor enables sophisticated control strategies across manufacturing, material handling, building automation, and process control environments requiring flexible, reliable automation solutions.

Core Technical Specifications

• Processor Architecture: High-speed 32-bit RISC processor for deterministic control
• Program Memory: 512 KB user program memory for complex applications
• Data Memory: 512 KB data memory for variables and buffers
• Scan Cycle Time: Fast execution with typical 1ms cycle for 1K instructions
• Ethernet Interface: 10/100 Mbps Ethernet port for network communication
• Communication Protocols: Modbus TCP, EtherNet/IP, IEC 61850, OPC UA
• Programming Languages: IEC 61131-3 (LD, FBD, ST, IL, SFC)
• I/O Capacity: Supports up to 4096 digital I/O points via modular expansion
• Operating Temperature: 0°C to +60°C industrial environment
• Power Supply: 24 VDC nominal (19.2-30 VDC range)
• Mounting: DIN rail mounting with snap-on retention
• Diagnostic Features: Built-in web server, LED status indicators, system diagnostics

Advanced PLC Processing Capabilities

The PM585-ETH incorporates sophisticated control processing and communication features designed for demanding industrial automation requirements:

• High-Performance Processing: 32-bit RISC architecture delivers fast scan cycles and deterministic execution essential for time-critical control loops, motion coordination, and synchronized machine operations
• Integrated Ethernet Connectivity: Built-in 10/100 Mbps Ethernet port enables direct connection to industrial networks, SCADA systems, and HMI panels without additional communication modules
• IEC 61131-3 Programming: Full support for five standard PLC programming languages (Ladder Diagram, Function Block Diagram, Structured Text, Instruction List, Sequential Function Chart) enables flexible application development
• Modular I/O Expansion: Scalable architecture supports local and distributed I/O modules via high-speed backplane and fieldbus networks, accommodating system growth from small machines to plant-wide automation
• Multi-Protocol Communication: Native support for Modbus TCP, EtherNet/IP, and OPC UA enables seamless integration with diverse field devices, drives, and enterprise systems
• Embedded Web Server: Built-in web interface provides remote diagnostics, program monitoring, and variable visualization through standard web browsers without additional software

Industrial Automation Applications

This AC500 processor module addresses diverse control requirements across industrial sectors where scalable, reliable automation directly impacts production efficiency and operational flexibility:

• Manufacturing Automation: Controls assembly lines, packaging machinery, and material handling systems with coordinated motion, sequential logic, and quality inspection integration in automotive, electronics, and consumer goods production
• Process Control Systems: Manages batch reactors, blending operations, and continuous processes with PID loops, recipe management, and regulatory control in food & beverage, pharmaceutical, and chemical manufacturing
• Building Automation: Coordinates HVAC systems, lighting control, access management, and energy monitoring in commercial buildings, data centers, and industrial facilities with BACnet and Modbus integration
• Water & Wastewater Treatment: Implements pump control, level regulation, chemical dosing, and filtration sequencing in municipal and industrial water treatment plants with SCADA connectivity
• Material Handling: Orchestrates conveyor systems, sortation equipment, automated storage/retrieval systems, and robotic palletizing in distribution centers and warehouses
• Machine Tool Control: Manages CNC machine tools, coordinate measuring machines, and automated inspection equipment with precision motion control and tool management
• Renewable Energy Systems: Controls solar tracking systems, wind turbine pitch/yaw mechanisms, and battery energy storage systems with grid integration and power management

AC500 System Architecture

The PM585-ETH functions as the computational core within ABB's AC500 modular PLC platform. The processor mounts on DIN rail with local I/O modules connecting via high-speed backplane, while distributed I/O communicates through Ethernet, PROFIBUS, or CANopen networks. Programming and configuration utilize Automation Builder software providing integrated development environment for logic programming, HMI design, and motion control. The system supports hot-swappable I/O modules and online program modifications for minimal downtime during maintenance.

Engineering Design Excellence

• Scalable Architecture: Modular design enables system expansion from standalone controllers to distributed automation networks with thousands of I/O points without processor replacement
• Redundancy Support: Hot-standby controller configurations with automatic failover ensure continuous operation in critical applications requiring high availability
• Cybersecurity Features: Integrated security protocols including user authentication, encrypted communications, and access controls protect against unauthorized access and cyber threats
• Diagnostic Intelligence: Comprehensive system diagnostics including I/O status, communication health, and program execution monitoring enable proactive maintenance and rapid troubleshooting
• Compact Form Factor: Space-efficient design minimizes panel real estate requirements while delivering high processing power and extensive I/O capacity
• Extended Service Life: Industrial-grade components and conservative thermal design ensure >10-year operational life with minimal maintenance requirements

Installation & Commissioning

The processor installs on standard 35mm DIN rail with snap-on mounting clips for tool-free installation. Power connects via screw terminals accepting 12-24 AWG wire, while Ethernet connection utilizes standard RJ45 connector. Configuration involves IP address assignment, program download via Automation Builder software, and I/O module configuration—typically completed in 30-45 minutes. Commissioning includes program verification, communication testing, and integration with HMI/SCADA systems.

Quality Standards & Compliance

Manufactured under ISO 9001:2015 quality management systems with complete component traceability. Complies with IEC 61131-2 programmable controller standards, CE electromagnetic compatibility directives (EN 61131-2), and UL 508 industrial control equipment specifications. Meets IEC 61010 safety requirements and RoHS environmental compliance. Suitable for installation in industrial environments per IEC 60068 environmental testing standards.
