Product Description
The PM863K01 Processor Unit HI is a high-integrity (HI) processor designed for safety-critical applications and certified for SIL3 compliance. It is part of the ABB AC 800M series and is used in 800xA safety systems. This processor requires configuration according to the Safety Manual and is only available to organizations that meet ABB's safety system qualifications.
Product Specifications
| Attribute | Details |
|---|---|
| Product ID | 3BSE088381R1 |
| ABB Type Designation | PM863K01 |
| Catalog Description | PM863K01 Processor Unit HI |
| Product Type | Central Unit |
| CPU Clock Frequency | 96 MHz |
| Memory Size | 32 MB |
| Compatibility | 800xA 6.1 and later, Control Builder Safe 3 and later |
| Certification | SIL3 (Safety Integrity Level 3) |
Package Includes
-
1 × PM863, Safety CPU
-
1 × TP830, Baseplate
-
1 × TB850, CEX-bus terminator
-
1 × TB807, ModuleBus terminator
-
1 × TB852, RCU-Link terminator
-
1 × Battery for memory backup (Part No. 4943013-6)
-
No license included
Dimensions & Weight
| Attribute | Details |
|---|---|
| Depth | 135 mm |
| Height | 186 mm |
| Width | 119 mm |
| Net Weight | 1.2 kg |
Ordering Information
| Attribute | Details |
|---|---|
| HS Code | 853710 (Electric control panels, consoles, desks, cabinets) |
| Customs Tariff Number | 85371091 |
| Country of Origin | China (CN) |
Environmental Compliance & Safety
| Attribute | Details |
|---|---|
| RoHS Status | Compliant with EU Directive 2011/65/EU |
| WEEE Category | 5 (Small Equipment - No External Dimension More Than 50 cm) |
| Dangerous Goods Class | Class 9 (Miscellaneous Dangerous Substances and Articles, Including Environmentally Hazardous Substances) |
| Dangerous Goods UN No. | UN3091-PI970 |
Battery Information
| Attribute | Details |
|---|---|
| Number of Batteries | 1 |
| Battery Chemical Composition | Lithium |
| Battery Type | Portable |
| Battery Weight | 9 g |
Categories
-
Products > Control Systems > 800xA > Controllers > AC 800M > Central Units
-
Parts & Services > Control Systems > 800xA > Controllers > AC 800M Hardware > Central Units
This processor unit is designed for safety applications requiring SIL3 certification and works exclusively with 800xA 6.1 or later. It is widely used in industries requiring high-integrity control systems, such as oil & gas, power generation, and chemical processing.
