ABB 1SDA080745R1 Emax 2 Circuit Breaker E2.2N1600

ABB 1SDA080745R1 Emax 2 Circuit Breaker E2.2N1600 - Advanced Power Protection

The ABB Emax 2 E2.2N1600 circuit breaker (part number 1SDA080745R1) represents the pinnacle of low-voltage power distribution protection technology. Engineered for demanding industrial and commercial electrical systems, this 1600A air circuit breaker (ACB) combines superior interrupting capacity, intelligent electronic trip units, and comprehensive communication capabilities to safeguard critical infrastructure while enabling predictive maintenance and energy management strategies.

Technical Specifications

• Part Number: 1SDA080745R1
• Series: ABB Emax 2
• Model: E2.2N1600
• Product Type: Air Circuit Breaker (ACB)
• Rated Current (In): 1600A at 40°C
• Poles: 3-pole configuration
• Rated Voltage (Ue): Up to 690V AC 50/60Hz
• Breaking Capacity (Icu): Up to 100kA at 415V
• Service Breaking Capacity (Ics): 100% of Icu
• Trip Unit: Electronic trip unit with LSIG protection functions
• Communication: Modbus RTU/TCP, Profibus DP, DeviceNet compatible
• Auxiliary Contacts: Configurable NO/NC contacts for status indication
• Operating Mechanism: Stored energy spring mechanism
• Electrical Endurance: 25,000 operations at rated current
• Mechanical Endurance: 50,000 operations
• Operating Temperature: -25°C to +70°C
• Mounting: Fixed or withdrawable execution
• Standards Compliance: IEC 60947-2, UL 1066, CSA C22.2 No. 31
• Certifications: CE, UL, cUL, CCC, EAC certified

Protection Functions & Trip Characteristics

The advanced electronic trip unit provides comprehensive protection:

• L (Long-time): Overload protection with adjustable time-current curves (0.4-1.0 x In), I²t or thermal memory characteristics
• S (Short-time): Short-circuit protection with adjustable delay (1.5-10 x In), enabling selective coordination
• I (Instantaneous): High-magnitude fault protection (2-15 x In) for immediate tripping
• G (Ground Fault): Earth leakage protection (0.2-1.0 x In) with independent time delay settings
• Zone Selective Interlocking (ZSI): Minimizes fault clearing time through coordinated protection schemes

Industrial Applications

The Emax 2 E2.2N1600 excels in high-power distribution scenarios:

• Manufacturing Facilities: Main distribution boards (MDB) and motor control centers (MCC) supplying heavy machinery, production lines, and material handling equipment in automotive, steel, and chemical plants
• Data Centers: Critical power distribution for UPS systems, PDUs, and IT load protection where reliability and monitoring are paramount
• Commercial Buildings: Main switchgear in high-rise offices, shopping malls, and hospitality complexes requiring intelligent load management and energy metering
• Infrastructure Projects: Substations, water treatment plants, and transportation hubs demanding robust protection and remote monitoring capabilities
• Marine & Offshore: Shipboard electrical systems and offshore platforms where space optimization and harsh environment resistance are critical

Engineering Solutions & System Integration

Selective Coordination: The E2.2N1600's adjustable short-time delay function enables selective coordination with downstream protective devices, isolating faults at the lowest possible level while maintaining power to unaffected circuits. This minimizes downtime and simplifies troubleshooting in complex distribution networks.

Energy Management Integration: Built-in power metering capabilities measure voltage, current, power factor, energy consumption, and harmonics. Integration with building management systems (BMS) or SCADA platforms via Modbus or Profibus enables real-time energy monitoring, demand response strategies, and cost allocation across multiple tenants or production areas.

Predictive Maintenance: The trip unit continuously monitors operating conditions including contact wear, number of operations, thermal stress, and fault history. Maintenance alerts and diagnostic data accessible through communication interfaces enable condition-based maintenance scheduling, reducing unplanned outages and extending equipment lifespan.

Arc Flash Mitigation: When integrated with arc flash detection systems, the Emax 2 can achieve ultra-fast tripping (within 50ms) to minimize arc flash incident energy, protecting personnel and equipment. The breaker's high breaking capacity ensures safe interruption even under severe fault conditions.

Common Technical Questions

Q: What is the difference between fixed and withdrawable execution?
A: Fixed execution breakers are permanently mounted in the switchgear, while withdrawable (plug-in) versions can be removed from the panel without disconnecting cables, facilitating maintenance and testing. The 1SDA080745R1 configuration should be verified based on your specific application requirements.

Q: Can this breaker be retrofitted into existing ABB Emax 1 panels?
A: Emax 2 breakers are designed with backward compatibility for many Emax 1 installations, though specific mounting dimensions and auxiliary device compatibility should be verified. Our technical team can assist with retrofit feasibility assessments and any required adapter kits.

Q: How do I configure the electronic trip unit settings?
A: Trip unit parameters are programmed using ABB's Ekip Connect software via USB or Bluetooth connection. Settings can be password-protected to prevent unauthorized changes. We recommend documenting all settings and performing coordination studies before commissioning.

Q: What communication protocols are supported for integration with our SCADA system?
A: The Emax 2 supports Modbus RTU (RS-485), Modbus TCP/IP (Ethernet), Profibus DP, and DeviceNet through optional communication modules. The breaker provides comprehensive data including real-time measurements, alarm status, and historical event logs.

Q: What maintenance is required for this circuit breaker?
A: Routine maintenance includes visual inspection, contact resistance measurement, insulation testing, and mechanical operation verification. ABB recommends maintenance intervals based on operating cycles and fault interruptions. The trip unit's diagnostic features provide guidance on when maintenance is needed.

Product Condition & Warranty Coverage

All ABB Emax 2 circuit breakers supplied by Industrial Control Hub are brand new, factory-sealed units sourced exclusively through authorized ABB distribution channels. Each breaker undergoes factory testing per IEC and UL standards and includes complete documentation, test certificates, and installation instructions. We provide a comprehensive 12-month warranty covering manufacturing defects, component failures, and performance issues. Our electrical engineering support team offers pre-sales application assistance, coordination studies, and post-installation technical support throughout the warranty period.

Related ABB Power Distribution Products

Complete your electrical distribution system with these complementary ABB components:

• ABB 1SDA080746R1 Emax 2 E2.2N2000 Circuit Breaker - Higher 2000A rating for increased capacity requirements
• ABB 1SDA080744R1 Emax 2 E2.2N1250 Circuit Breaker - 1250A model for medium-duty applications
• ABB 1SDA067768R1 Tmax XT MCCB - Molded case circuit breaker for downstream protection

Global Shipping & Technical Support

Industrial Control Hub maintains ready inventory of ABB Emax 2 circuit breakers for immediate worldwide shipment. We provide specialized packaging with shock-absorbing materials to protect sensitive electronic components during transit, full tracking visibility, and expedited shipping options for urgent project deadlines. Our electrical engineers offer comprehensive pre-sales support including short-circuit calculations, selective coordination studies, and arc flash analysis to ensure proper breaker selection and system design.
