Product Description
General Information
|
Field |
Details |
|---|---|
|
Manufacturer |
ABB |
|
Product ID |
57160001-TZ |
|
ABB Type Designation |
DSTD 110A |
|
Catalog Description |
DSTD 110A Connection Unit for Digital |
|
Long Description |
DSTD 110A Connection Unit for Digital Output Board, 32 channels, max 60 VIncludes mounting screws kit reference: 3BSE021202R1 |
|
Medium Description |
Connection Unit |
|
Product Type |
I-O_Module |
Technical Information
|
Field |
Details |
|---|---|
|
Application |
For use with Digital Output Boards |
|
Channels |
32 |
|
Voltage Rating |
Max 60 V |
|
Exchange Number |
EXC57160001-TZ |
|
Mounting Kit |
3BSE021202R1 |
Ordering Information
|
Field |
Details |
|---|---|
|
HS Code |
853890 |
|
Customs Tariff Number |
85389091 |
Dimensions and Weight
|
Field |
Details |
|---|---|
|
Net Depth / Length |
324 mm |
|
Net Height |
54 mm |
|
Net Width |
157.5 mm |
|
Net Weight |
0.365 kg |
Environmental Information
|
Field |
Details |
|---|---|
|
RoHS Compliance |
Exempt from scope per 2011/65/EU Article 2(4)(c), (e), (f), (j) |
|
WEEE Category |
5. Small Equipment (No External Dimension More Than 50 cm) |
|
Number of Batteries |
0 |
|
SCIP Number |
be89e5b5-dfc7-4171-95e3-860357096ccc (Sweden) |
Product & Parts Hierarchy
-
Products › Control System Products › I/O Products › S100 I/O › S100 I/O - Termination Units › DSTD 110A Connection Units
-
Products › Control Systems › Advant OCS with Master SW › Controllers › Advant Controller 450 › Advant Controller 450 Version 2.3 › I/O Modules
-
Parts & Services ›
-
Control Systems › 800xA › I/Os › S100 I/O › I/O Modules
-
Control Systems › Advant OCS with Master SW › Controllers › MasterPiece 200 and 200/1 › I/O Modules
-
Control Systems › Advant OCS with MOD 300 SW › I/Os › S100 I/O › I/O Modules
-
Compact Product Suite › I/Os › S100 I/O › I/O Modules
